Dynamic Characteristics of a High Speed Precision Positioning Platform Driven by Linear Motors

Abstract:

Positioning systems with higher speed and accuracy are required in semiconductor package manufacturing, and the product quality and production efficiency can be further improved. So this paper presents a new 2-DOF precision positioning platform with high speed. The platform is directly driven by linear motors, and a novel elastic decoupling mechanism is put forward. High positioning accuracy and good stability in a short stroke, high precision and high speed movement can be achieved using linear motors. The X axis and Y axis kinematic decoupling is realized through the novel elastic decoupling mechanism based on a preloaded spring and flexure hinges, and the dynamic characteristics of the system are improved. The dynamic characteristics of the positioning platform in free state are investigated based on finite element analysis, and the natural frequencies and vibration modes of the positioning platform are obtained, which provides theoretical basis for the further dynamic control of the positioning platform.

• Periodical: Applied Mechanics and Materials (Volume 197)
• Pages: 46-49
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.197.46
• Online since: September 2012
• Authors: He Ying Wang, Fu Jun Wang, Xing Yu Zhao, Y.G. Shi, Da Wei Zhang
• Keywords: Dynamic Characteristic, Elastic Decoupling Mechanism, Linear Motors, Positioning Platform

References

[1] Cheng Li, Li Chun Ming, Wang Zhen Yu, Application of new technologies in the IC industry chain and development strategy, Semiconductor Technology, 2004, 6(29): 57-63.

[2] M. Rajeswari, M.G. Rodd, Real-time analysis of an IC wire-bonding inspection system, Real-Time Imaging, 1999, 5: 409-421.

DOI: 10.1006/rtim.1998.0149

[3] Kazuto Nishida, Kazumichi Shimizu, Michiro Yoshino, Reliability evaluation of ultra-thin CSP using new . ip-chip bonding technology–double-sided CSP and single-sided CSP, Microelectronics Reliability, 2003, 43: 2065~(2075).

DOI: 10.1016/s0026-2714(03)00166-5

[4] Wang Zhi Yue, Advanced manufacturing technology-IC and MEMS manufacturing technology and its development trend, Equipment for Electronic Products, 2002, 4(31): 187~195.

[5] S. Endo, H. Kobayashi, C.J. Kempt, et al. Robust digital tracking controller design for high-apeed positioning system, Control Eng. Practice, 1996, 4(4): 527~536.

DOI: 10.1016/0967-0661(96)00036-6

[6] Akira Tamaki, Means for location an ultra-precision position of a table, U.S. Patent, No. 4, 590, 380, 1986, May. 20.

[7] Ronald K. Kerschner, Differential motor drive for an XY stage, U.S. Patent, No. 006, 070, 480 A, 2000, Jun. 6.

[8] Ken Yanagisawa, et al. Two dimensional drive system, U.S. Patent, No. 006, 327, 929 B1, 2001, Dec. 11.

[9] Nobuto Yamazaki, Minoru Torihata, X-Y table for bonding devices, U.S. Patent, No. 005, 157, 985 A, 2000, Oct. 27.

[10] Toru Oshima, Method and apparatus for processing workpiece by using X-Y stage capable of improving position accuracy, U.S. Patent, No. US2002/0, 180, 133 A1, 2002, Dec. 5.

[11] Bin Yao, Li Xu, Adaptive robust motion control of linear motors for precision manufacturing, Mechatronics, 2002, 12: 595~616.

DOI: 10.1016/s0957-4158(01)00008-3
