Development and Current Status of Multi-Level Converter

Abstract:

The multi-level converter is one of the focuses in the current high-voltage high-power field of power conversion, and is found widely application in high power drive system. It generated so far for nearly three decades of history. During this period a large number of multi-level topology appeared, there are three most commonly used, which are diode clamped, capacitor and cascaded H-bridge. In this paper, the development of the multi-level converter is reviewed. The structure of three multi-level converter topologies are given, and then their advantages and disadvantages are given by analyzing and comparing their characteristics. Finally, a new modular multi-level converter (MMC) is introduced which is one of research focus of multi-level converter field at present. Its structure and working principle are described in detail. Multi-level converters will continue to be developed to meet the demand of high-voltage and high power applications.

• Periodical: Applied Mechanics and Materials (Volumes 201-202)
• Pages: 95-98
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.201-202.95
• Online since: October 2012
• Authors: Yan Xie, Bo Chao Chen, Yao Jun Chen
• Keywords: Circuit Topology, Modular, Multilevel Converter

References

[1] R. Chen: Wuhu Vocational and Technical College, Vol. 12 (2010) No.2, pp.21-24.

[2] G.J. Ding, M.Ding, G.F. Tang, Z.Y. He: Proceedings of the CSEE, Vol. 29(2009) No.30, pp.1-6 (in Chinese)．

[3] W.L. Pan, Z.Xu, J.Zhang, C.Wang. Proceedings of the CSEE, Vol. 28 (2008) No.21, pp.7-14 (in Chinese).

[4] Q.R. Tu, Z.Xu, X. Zheng, M.Y. Guan: High Voltage Engineering, Vol. 36 (2010) No. 2, pp.547-552．

[5] Q.R. Tu, Z.Xu, M.Y. Guan, X. Zheng, J. Zhang: Automat ion of Electric Power Systems, Vol. 34 (2010) No.18: 57-61．

[6] S.S. Wang, X.X. Zhou, G.F. Tang, Z.Y. He, L.T. Teng, H.L. Bao: Proceedings of the CSEE,Vol. 31, (2011), No.1, pp.1-7 (in Chinese).
