Numerical Analysis of Variation Law about Vertical Additional Force of Monolayer Shaft Lining

Abstract:

The shaft lining under the deep alluvium drainage and grouting settlement stratum are in the complex dynamic force state, the stresses of shaft lining have a relation to the consolidation settlement of strata, the transmission coefficient of bottom aquifer and the coupling effect between shaft lining and surrounding soil. To study the variation law about vertical additional force of shaft lining, this paper analyzes reinforced concrete monolayer shaft lining by numerical simulation method, obtaining that vertical additional force of monolayer shaft lining is proportional to the modulus of elasticity of shaft lining concrete and it is proportional logarithm to the transmission coefficient of bottom aquifer, meanwhile, founding that shaft lining’s stress-strain relationship is dynamic when the composite loads are applied and that the plastic zone of shaft lining is resulted from coupling of multiple loads. Therefore, decreasing the transmission coefficient of bottom aquifer and the elasticity modulus of shaft lining concrete is beneficial to reduce the vertical additional force of shaft lining and increases the stability of shaft lining.

• Periodical: Applied Mechanics and Materials (Volumes 204-208)
• Pages: 4624-4628
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.204-208.4624
• Online since: October 2012
• Authors: Xi Liang Liu, Jun You Hou
• Keywords: Coupling, Elasticity Modulus, Permeability Coefficient, Vertical Additional Force

References

[1] Xiliang Liu. The Shaft Lining Stress Study in Deep Alluvium Unstable Strata (Coal Industry Press, China 2004). (In Chinese)

[2] Guangxin Cui. Mine Construction Technology Vol 19 (1998), p.29. (In Chinese)

[3] Guangxin Cui. Chinese Journal of Geotechnical Engineering Vol 25(2003), p.294. (In Chinese)

[4] Zhonghua Li and Yishan Pan. Engineering Mechanics Vol 19(2002), p.105. (In Chinese)

[5] Jun Su. Journal of Rock Mechanics and Geotechnical Engineering Vol 24(2005), p.139. (In Chinese)

[6] Jie Gao, Zaiquan Wang, and Jinyao Chen, et al .Journal of Underground Space and Engineering Vol 5(2009), p.873.( In Chinese)

[7] Xiaoqin Li and Wenping Li. Journal of Geotechnical Engineering Vol 27(2005), p.329. (In Chinese)

[8] Xiliang Liu and Tingshun Zhang. Journal of Mining and Safety Engineering Vol 20(2003), p.1. (In Chinese)

[9] Junjie Yang. The Shaft lining structure in Deep Alluvium Strata (Science Press, China 2010). (In Chinese)
