Study on Wear Behaviors and Grain Effects of PCD Cutting Tools in Turning Granite

Abstract:

In this paper, three types of polycrystalline diamond (PCD) tools marked as PCD 030, PCD 010 and PCD 005 (equivalent to 30, 10, and 5μm average grain size of original diamond) were tested, and their wear behaviors was studied. The wear of PCD cutting tools in machining granite bars was invested by a turning process. The experiments were carried out under wet condition. Wear volume was measured by optical microscopy and wear morphology was examined by scanning election microscopy (SEM) and optical microscopy. By comparing the flank face, the experiments results show that the PCD tools with coarse original diamond grain size have long life at three cutting speeds, and the tool life of the three PCD tools decreases with the increase of cutting speed. SEM morphology by secondary electron image analysis indicates that the dominant wear mechanism for PCD 010 and PCD 005 is abrasive wear. While for PCD 030, the abrasive wear mechanism is predominant wear in the machining, occasionally some cleavage wear are also observed.

• Periodical: Applied Mechanics and Materials (Volume 214)
• Pages: 130-135
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.214.130
• Online since: November 2012
• Authors: Shen Zhuo Liu, Zi Li Kou, Rui Zhang, Cheng Liang Liu, Yu Li, Rong Qi Li, Xiao Zhi Yan
• Keywords: Grain Effects, Polycrystalline Diamond (PCD), Wear

References

[1] J. Paulo Davim, A. Monteiro Baptista, Relationship between cutting force and PCD cutting tool wear in machining silicon carbide reinforced aluminium, Journal of Materials Processing Technology 103 (2000) 417-423.

DOI: 10.1016/s0924-0136(00)00495-7

[2] K. Palanikumar, Application of Taguchi and response surface methodologies for surface roughness in machining glass fiber reinforced plastics by PCD tooling, Int J Manuf Technol (2008) 36: 19-27.

DOI: 10.1007/s00170-006-0811-0

[3] P. Philbin, S. Gordon, Characterisation of the wear behaviour of polycrystalline diamond (PCD) tools when machining wood-based composites, Journal of Materials Processing Technology 162-163 (2005) 665-672.

DOI: 10.1016/j.jmatprotec.2005.02.085

[4] R.M. Hooper, J.L. Hen shall, A. Klopfer, The wear of polycrystalline diamond tools used in the cutting of metal matrix composites, International Journal of Refractory Metals & Hard Materials 17 (1999) 103-109.

DOI: 10.1016/s0263-4368(98)00040-7

[5] K. Weinert, A consideration of tool wear mechanism when machining metal matrix composite (MMC), Ann. CIRP 42 (1993) 95-98.

DOI: 10.1016/s0007-8506(07)62400-7

[6] J.E. Caroline, Andrewes, H.Y. Feng, W.M. Lau, Machining of an aluminum/SiC composite using diamond inserts. Journal of Materials Processing Technology 102 (2000) 25-29.

DOI: 10.1016/s0924-0136(00)00425-8

[7] J. Paulo Davim, Diamond tool performance in machining metal–matrix composites. Journal of Materials Processing Technology 128 (2002) 100–105.

DOI: 10.1016/s0924-0136(02)00431-4

[8] Y. Kevin Chou, Jie Liu, CVD diamond tool performance in metal matrix composite machining, Surface & Coatings Technology 200 (2005) 1872 – 1878.

DOI: 10.1016/j.surfcoat.2005.08.094

[9] J.A. Arsecularatne, L.C. Zhang, C. Montross, Wear and tool life of tungsten carbide, PCBN and PCD cutting tools, International Journal of Machine Tools & Manufacture 46 (2006) 482–491.

DOI: 10.1016/j.ijmachtools.2005.07.015

[10] I. Ciftci, M. Turker, U. Seker, CBN cutting tool wear during machining of particulate reinforced MMCs, Wear 257 (2004) 1041-1046.

DOI: 10.1016/j.wear.2004.07.005

[11] Y. Kevin Chou, Chris J. Evans, Moshe M. Barash, Experimental investigation on CBN turning of hardened AISI 52100 steel, Journal of Materials Processing Technology 124 (2002) 274-283.

DOI: 10.1016/s0924-0136(02)00180-2

[12] R. Zhang, Z.L. Kou, Y.E. Dou, S.Z. Liu, Wear behaviors of PCD tools in turning granite. Advanced materials Reserch Vol 337 (2011) pp.728-734.

DOI: 10.4028/www.scientific.net/amr.337.728

[13] Y. Li, X.L. Han, X.Q. Wang. Reserch on mechanical properties and test methods of polycrystalline diamond. Diamond Abras Eng2001; 5: 27-30 [in Chinese].

[14] Q.S. Bai, Y.X. Yao , Phillip Bex , G. Zhang , Study on wear mechanisms and grain effects of PCD tool in machining laminated flooring, International Journal of Refractory Metals & Hard Materials 22 (2004) 111-115.

DOI: 10.1016/j.ijrmhm.2004.01.007
