Integrated Instrument Based on SOPC

Abstract:

This instrument based on SOPC technology is embedded with a NIOS soft-core in Cyclone III as a control center that integrates digital oscilloscope, DDS signal generator and a simple digital multi-meter. It can measure AC signal of 200 Hz-5MHz and 10mVpp-10Vpp, display and store the wave, and can also manually and automatically adjust the amplitude and frequency. This instrument can generate sine wave of 10Hz to 1.5MHz, square wave of 10Hz to 200 KHz, triangle wave, and saw-tooth wave vary from 150mVpp to 10Vpp. Also, it can measure AC and DC voltage of 20mV to 200V, the AC and DC current of 2mA to 1A, resistance of 20Ω to 2MΩ, maintaining 5% accuracy. It is simple, easy to use, can fulfill the general experiment requirements with good performance and strong practicability.

You might also be interested in these eBooks

Green Power, Materials and Manufacturing Technology and Applications II

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 214)

Pages:

141-147

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.214.141

Citation:

Cite this paper

Online since:

November 2012

Authors:

Zheng Ma, Ming Liu Liu, A Hui Yang, You Yang Liu

Keywords:

DDS Signal Generator, Digital Multi-Meter, Digital Oscilloscope, NIOS Soft-Core

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Yuwen Xia. Digital System Design-Verilog Implementation (2nd edition). Beijing: Higher Education Press, (2006).

Google Scholar

[2] [U.S. ] Beth. Translated by Leng Liu, Yongsheng Hu. FPGA Implementation of Digital Signals Processing. Beijing: Tsinghua University Press, (2002).

Google Scholar

[3] Genchun Huang, Xiaoqiao Chen, Wangxian Zhang. Electronic Design Guide. Beijing: Electronics Industry Press, 2007. 8.

Google Scholar

[4] Zimei Xie. Electronic Circuit Design • Experiment • Test (2nd Edition). Wuhan: Huazhong University of Science and Technology Press, 2007. 7.

Google Scholar

[5] Lanying Li. Nios II Embedded Soft-core SOPC Design Principles and Applications, Beijing: Beijing University of Aeronautics and Astronautics Press, 2006. 11.

Google Scholar

[6] Chenglian Peng. SOPC Design in Practices based on NIOS. Beijing: Tsinghua University Press, 2006. 11.

Google Scholar

[7] Hui Qin, Jing Li, Beibei Dong, Yanxia Liu, Xiaoguang Zhang. Design of Full Automatic Digital Multi-meter. Automation & Instrumentation, 2010. 1.

Google Scholar
