Application of Rigid-Flexible Coupling in Stiffness Calculation of Double Wishbone Suspension

Abstract:

Based on multi-body Dynamics theory, the 1/4 multi-rigid model of double wishbone suspension of automobile in ADAMS/View is created, and use ANSYS software to analyze torsion beam flexibility. Furthermore, the rigid-flexibility model has been created and the rigid change of suspension line along with the tire dynamics change is simulated. The result shows that the rigid-flexible coupling model is more accuracy than the multi-rigid one and fits the practical situation even better. This paper proposes an efficient method for analyzing the rigid of double-wishbone suspension vertical line.

• Periodical: Applied Mechanics and Materials (Volume 214)
• Pages: 161-164
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.214.161
• Online since: November 2012
• Authors: H.N. Wang, X.W. Hou, X.P. Su
• Keywords: Double Wishbone Independent Suspension, Multibody Dynamics (MBD), Rigid-Flexible Coupling, Suspension Stiffness, Torsion Spring

References

[1] J. Li,H.J. Zou,H. Guo. Design and Experiment of Torsion Bar Spring for HJL1020. Machine Design and Research, 2002, (4): p.57.

[2] Y.H. Deng Y.J. Hu,Y.C. Yang. Matching of rigidity and equip-intensity design of twin torsion bar in double wishbone suspension with twin torsion bar. Engineering Design, 2002, (9): p.44.

[3] S.T. Zhou H.W. HUANG,W.Y. Zhu. Optimization design of torsion bar of double wishbone suspension based on random vibration analysis method. Journal of Central South University, 2011, (12): p.3736.

[4] M.J. Luo W.L. Wang. Finite element analysis and structural optimization on double-wishbone independent suspension with torsion. Machinery Design & Manufacture, 2009, (7): p.19.

[5] SH. CH. Li,D.K. Chen,F. Ge, Stiffness Calculation and Force Analysis of Double Wishbone Independent Suspension w ith Torsion Bar. Journal of Academy of Military Transportation, 2010, (1): p.51.

[6] GU Xinzhong, ZHANG Tieshan. The Match of Stiffness between Front and Rear Suspension. MECHANICAL ENGINEER. 2011, (1): p.3.

[7] X.Z. Cheng L.Q. Chen. Stiffness Calculation of Suspension with Torsion-bar Double Wishbone Based on ADAMS. Tractor& Farm Transporter, 2008, (2): p.17.

[8] SH.Y. DUAN, A passenger car suspension K&C characteristics analysis and its matching research[D]. Guangxi University of Technology , 2010, (1): p.3.

[9] Q.D. Wang W.W. Chen W.H. He. Stiffness Calculation of an Independent Suspension with Double Wishbone Based on Multi-body Dynamics. Transactions of the Chinese Society of Agricultural Machinery, 2004, (35): p.132.

[10] WANG Nan, WANG Jing, PING Enshun. Kinematics modeling and simulation of double wishbone suspension basedon ADAMS/Car. MECHANICAL ENGINEER. Journal of Hebei University of Engineering. 2010, (12): p.55.
