A Research on the DC-Link Current and Capacitance of the Static Excitation Regulator on a 12/3-Phase Dual Stator-Winding Induction Generator

Abstract:

By proper simplifications, the static excitation regulator on the 12/3 phase dual stator winding induction generator is described by the switch-function model. On this basis, the switch-function expression of the DC-link capacitor current is obtained and the physical meanings are discussed, and the detailed exchange procedures between the generator and capacitor are analyzed. Considering the voltage endurance capability of the capacitor and IGBT, and the current endurance capability of the capacitor, the limitation capacitance equation of the DC-link capacitor is proposed.

• Periodical: Applied Mechanics and Materials (Volume 214)
• Pages: 154-160
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.214.154
• Online since: November 2012
• Authors: Bo Tao Zhang, Dong Wang
• Keywords: Dual Stator-Winding Generator, Harmonic, PWM, Static Excitation Regulator, Switch Function

References

[1] Nie Zining, Zhang Botao. The 2nd Harmonic Calculation of the Capacitor Voltage in the DC Link of the Cascade H-Bridge SVG [J]. Trans. Of China Electrotechnical Society, Vol. 21, No. 4, PP. 112-116.

[2] Zhang Botao, Nie Zining, Libei, Zhang Liping. Analysis of the DC-Link Capacitor Voltage Spectrum in the Cascaded Multilevel STATCOM[J]. ICIT 2008, PP. 1-5.

DOI: 10.1109/icit.2008.4608454

[3] Zhang Botao, Ma Weiming. Research on the control algorithm and dynamic characteristic of a 12/3-phase dual stator winding induction generator. Proceedings of CSEE, Vol. 25, No. 12, PP. 143-148.

DOI: 10.1109/iecon.2005.1569155

[4] Wang Dong, Ma Weiming. Study On the Currents of Sudden DC-side Shout Circuit of a 12/3 Phase Dual stator-winding Induction Generator[J]. Proceedings of CSEE, Vol. 25, No. 15, PP. 133-139.

[5] Xiao Fei, Zhang Botao. A Double-winding Induction Generator and Its Excitation Strategy. Power System and Automatic, Vol. 27, No. 18, PP. 26-29.

[6] Wang Dong, Ma Weiming. Analysis On The Harmonic Asymmetry of 12/3-Phase Dual Winding Induction Generator[J]. Proceedings of CSEE, Vol. 24, No. 5, PP. 148-152.

[7] Gu WeiFeng Ma Weiming. Research On the Harmonic Resonance of the 12/3 Phase Double-winding Asynchronous Generator during its Self-Excitation[J]. Proceedings of CSEE Vol. 24, No. 6, PP. 167-171.

[8] Prasad N. Enjeti, Phoivos D. Ziogas, Mehrdad Ehsani. Unbalanced PWM converter analysis and corrective mearures[J]. IAS Annual Meeting, 1989, Vol. 1, PP. 861-870.

DOI: 10.1109/ias.1989.96745

[9] Wang Zaoan, Yang Jun, Liu Jinjun. Harmonic eliminate and reactive power compensation[M]. Mechanism Industry Press.

[10] Fang Zheng Peng, John W. McKeever. A power line conditioner using cascade multilevel inverters[J]. IEEE Trans on Industrial Application, 1998, 34(6), PP. 1293-1298.

DOI: 10.1109/28.739012
