Optimization Design and Simulation of Negative-Pressure Removing-Chip Mechanism of Deep Hole

Abstract:

In the deep-hole drilling process, chips can not be easily removed, so the influence factors of the negative-pressure removing-chips were analyzed on the existing DF negative-pressure removing-chip mechanism by the hydraulic pressure theory and the injection angle κ and negative pressure gap S were analyzed with FLUENT software. The results show that negative pressure effect were best in 32°of κ and 0.4 mm of S and negative pressure effect are better in 28°of κ and 0.5mm of S , which lay good theoretical foundation for the optimization and characteristics of negative pressure mechanism in near-dry deep-hole drilling.

• Periodical: Applied Mechanics and Materials (Volumes 215-216)
• Pages: 105-110
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.215-216.105
• Online since: November 2012
• Authors: Biao Wang, Li Qin Zhao, Qing Yan Ma
• Keywords: Injection Angle, Negative-Pressure Gap, Negative-Pressure Removing-Chip, Optimization

References

[1] Feng Cheng and Shixi Guan: Manufacturing Technology & Machine Tool. Vol.1(2009), P.119-122. (In Chinese).

[2] Xinyong Li, Biao Wang and Zhaohua Liu:Machinery Design＆Manufacture.Vol.3 (2011), P.213-215. (In Chinese).

[3] Shixi Guan and Feng Cheng: Machinery Design＆Manufacture, Vol.5(2009), P.112-114. (In Chinese).

[4] Zhimin Wang and Zhide Mi: New Technology & New Process.Vol.2(1990), P.30-31. (In Chinese).

[5] Huilin Wang and Pingkuan Zhang: Tool Technology. Vol.10(1998), P.14-16. (In Chinese).

[6] Xibin Wang: Chinese Journal of Mechanical Engineering. Vol.36(2006), P.6 -10. (In Chinese).

[7] Zujun Ma and Yin Dai: Manufacturing Technology & Machine Tool. Vol.1(2007), P.41-43. (In Chinese).
