A Novel Radial Telescopic Tire Building Drum and its Kinematics Design

Abstract:

A novel radial telescopic tire building drum is proposed to meet the radial tire production requirements. After the discussion of the mechanical structure and transmission principle of this mechanism, the kinematics equations together with the formulas of contraction ratio and pressure angle are established. In order to optimize the characteristics of force-transfer, when taking the interference condition into consideration, a kinematics design method of this novel radial telescopic building drum is proposed, which can obtain the minimal value of mechanism maximum pressure angle and satisfy the demand of contraction ratio. The most important feature of this building drum is that the external shell is driven by the internal shell. Designer can derivative more design schemes by applying this transmission principle.

• Periodical: Applied Mechanics and Materials (Volumes 215-216)
• Pages: 207-211
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.215-216.207
• Online since: November 2012
• Authors: Yun Long Wang*, Lei Zhang, Yu Hu Yang
• Keywords: Constraint Equations, Contraction Ratio, Kinematics Design, Tire Building Drum

References

[1] X.G. Chen, B.He: Tire Industry. Vol. 24(5)(2004), pp.297-300 In Chinese

[2] L.Q. Zhong, China Patent 200810107407.(2009) In Chinese

[3] Z.C. Dai, G.X. Shen and M. Hu, China Patent 200810071027.4.(2009) In Chinese

[4] Y.T. Geng, J.L. Xu and L.G. Geng, China Patent 200820020629.2.(2009) In Chinese

[5] Y.Z. Xie, China Patent 200620083428.8.(2006) In Chinese

[6] W.Q. Huang and J. Zhou, China Patent 200710050947.3.(2008) In Chinese

[7] B. Painter, U.S. Patent 20090056879A1.(2009)

[8] C.A. Roberts and M.S. Byerley, U.S. Patent 6058999. (2000)

[9] Z.H. Guo, K.J. Wang and H.L. Qi, China Patent 200820025802.8.(2009) In Chinese

[10] H.L. Qi, Z.H. Guo, L. Hu and H.P. Song: Journal of Shandong University of Technology. Vol. 24(3)(2010), pp.49-55 In Chinese
