Optimizing Design System of Four Linkage Mechanism in Hydraulic Support Based on VC + +

Abstract:

Based on the analysis of hydraulic support design variables, a set of hydraulic support mechanism optimization design system has been developed with VC++ language. Design optimization of hydraulic powered support system instead of manual design and greatly shortened the design cycle and improves the accuracy of the design. This paper also analyzes two structural dimensions of the four linkage structure-the horizontal distance and vertical distance between the lower hinge point on the base of the front connecting rod and the rear connecting rod. By the analysis size range of the two structural dimensions has been found. It is Very valuable for designing hydraulic support.

• Periodical: Applied Mechanics and Materials (Volumes 215-216)
• Pages: 50-53
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.215-216.50
• Online since: November 2012
• Authors: Wen An Gao*, Ju Lin Wang
• Keywords: Fast Optimization, Four Bar Linkage, Hydraulic Support, Structure Size

References

[1] Li bintao. Localization high-end hydraulic supporting development [J]. Coal mine machinery, 2008.9,29(9):3-5.

[2] Wang jianguo. Hydraulic support four bar linkage optimization design based on the MATLAB [J]. Coal mining,2010.4(1):201-205.

[3] Rao mingjie. Optimizing design system of four linkage mechanism in hydraulic support based on VC + +[M]. Coal mine machinery, 2011.11:325-456.
