The Mechanism Analysis and Trajectory Simulation of 5R Joint Manipulator

Abstract:

5R joint manipulator kinematics model of position module is established, and according to the D-H method kinematical analyse of manipulator is processed, the space pose transformation matrix between adjacent rods of manipulator is established. The position equations of the manipulator is obtained and the Forward & Inverse solution of kinematics are got. The correctness of the forward & inverse solution are also verified through a engineering examples.

• Periodical: Applied Mechanics and Materials (Volumes 220-223)
• Pages: 1744-1747
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.220-223.1744
• Online since: November 2012
• Authors: Ke Tao, Yuan Yuan Zhang, Zhi Jun Wang, Ping Ping Song
• Keywords: 5R Joint Manipulator, Forward Solution, Inverse Solution, Kinematics

References

[1] Youlun Xiong. Robotics[M]. Wuhan, Huazhong University of Science and Technology Press, 2011.

[2] Bopeng Zhang, Kun Zhang, Jiaqiu Xu. Robot engineering[M]. Beijing Mechanical Industry Press,1989.

[3] Craig J J.Introduction to Robotics[M].New York:Addison-Wesky Publishing Co, 1989.

[4] Zixing Cai. The robotics[M]. Beijing, Tsinghua University Press,2000.

[5] Clark D.M ichael Ow ings: Building Robot Drive Trains[M]. TheMcGraw-HillCompanies, Inc,2003.

[6] Ping Chen, Guohai Liu. MOTOMAN-UPJ type manipulator kinematics algorithm [J]. Mechanical transmission,2006,30(4):23-27.
