Non-Linear Error Analysis of the Variable Pole Pitch Capacitive Sensor

Abstract:

The output characteristics of the variable pole pitch capacitive sensor is introduced, the relationship between non-linear error and range is analyzed respectively using theoretical fitting，zero-crossing rotation fitting and best uniform approximation fitting，theoretical expression is derived，and examples of calculations and MATLAB simulation are carried out. It has turned out that the expression based on the best uniform approximation fitting is more reasonable, having higher accuracy, and non-linear error is apparently reduced when the input of relative variation is the same; while in the given nonlinearity conditions, the range was significantly increased. To some extent, this provides theoretical guidance to the design and application of the variable pole pitch capacitive sensors.

• Periodical: Applied Mechanics and Materials (Volumes 220-223)
• Pages: 1861-1864
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.220-223.1861
• Online since: November 2012
• Authors: Ke Qin Liu, Mei Feng Zhang, Xue Tao Pan
• Keywords: Capacitance Sensor, Nonlinearity Error, Range

References

[1] Qiang Xifu, in:Sensors. edtied by Machinery Industry Press,Beijing, CHINA(2001), in press.

[2] Pan Xuetao, in:Sensor Principle & Detecting Technology. edtied by National Defense Industry Press, Beijing, CHINA(2011), in press.

[3] Zeng Jinping, in: Numerical Calculation Method . Hunan: edtied by Hunan University Press, Changsha, CHINA(2004), in press.

[4] Wu Baoming, Lee Shengfei: Chinese Journal of Sensors and Actuators Vol. 10 (2010),p.1788.

[5] Pan Xuetao, Wu Jiawei: Electronic Components and Materials Vol. 2(2007), p.27.
