Design of the Data Acquisition System for Mine's Dynamic Rail Track Scale

Abstract:

The data acquisition system for mine's dynamic rail track scale is designed based on embedded technology. The automatic motion direction judge of the tramcar could be achieved by the staggered installation of the weight sensors without installing additional direction sensors. Each pair of tracks are installed with a data collector and all data collectors carry out a two-way data exchange with the same measurement controller. A video monitor is installed near the coal mines to get video monitoring. Only one video server is required for all video monitors. The measurement controller is used to receive and deal with both the weight data from the data collector and the video data from video server. The data is computed in measurement controller and transmitted to the remote monitoring center server, in which the final results are presented.

• Periodical: Applied Mechanics and Materials (Volumes 220-223)
• Pages: 2040-2043
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.220-223.2040
• Online since: November 2012
• Authors: Chuan Xing Zheng, Jian Chen
• Keywords: Data Acquisition, Dynamic Rail Track Scale, Embedded Technology, Sensor

References

[1] Entao Yao, Juan Ji, and Ming Zhang: Sensor Technology, Vol. 24(2005), p.22

[2] Zhifeng Zhou, Ping Cai, Jia Xu: China Mechanical Engineering, Vol. 16(2005), p.1813

[3] Guangyue Xu: Sensor Applications, Vol. 7(1989), p.11

[4] Chuanxing Zheng, Jian Chen, Jianzhong Chen: BMEI 2011-Proceedings, Vol. 1(2011), p.686
