Characteristics Analysis of Working Mechanisms for Servo Mechanical Presses

Abstract:

Based on analysis of press working characteristics, some of the main kinematics requirements for working mechanisms of servo mechanical presses were put forward: fast in empty stroke, slow and uniform in working stroke and big force gain. Crank link and knuckle-straight link are the most common working mechanisms in mechanical presses. To meet the requirement of servo mechanical presses, another mechanism, knuckle-triangle link, was designed. The kinematics simulations of the three mechanisms for a 1600kN press were conducted by dynamic software ADAMS. Knuckle-triangle link had the most uniform and lowest slide’s average velocity and biggest force gain within the working stroke. For the same nominal pressure of 1600kN, the required input torque of knuckle-triangle link was 9108Nm. In comparison with crank link and knuckle-straight link, the crank’s input torque was reduced by 84% and 76% respectively without considering the influence of friction and inertia. In conclusion, knuckle-triangle link mechanism is more suitable for large-tonnage servo presses.

• Periodical: Applied Mechanics and Materials (Volumes 220-223)
• Pages: 762-767
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.220-223.762
• Online since: November 2012
• Authors: You Song Sun, Jian Guo Hu, Yong Qi Cheng, Wei Ping Ruan
• Keywords: Dynamic, Kinematics, Mechanical Design, Servo Mechanical Presses, Working Mechanisms of Presses

References

[1] K. Miyoshi, Current Trends in Free Motion Presses, Proceedings of 3rd Japan Society for Technology of Plasticity (JSTP) International Seminar on Precision Forming, presentation slides, Japan, March 2004.

[2] A. Mark Sutton，Servo Press Technology Saving Energy in the Pressroom， presentation slides, Energy Conference and Exhibition 2008，May 6， 2008， Novi， Michigan.

[3] He, D.Y. Crank Presses, Mechanical Engineering Press, Beijing, 1984.

[4] Sun, Y.S., Zhou, X.H., Wei, L.M. et al. AC servo presses and their key technologies. Forging & Stamping Technology, 2008,33(4):1-8.

[5] Sun, Y.S., Hu, J.G., Zheng, H.B. et al. Energy saving drive for forming equipment. Advanced Materials Research, 154-155(2011):701-707.

DOI: 10.4028/www.scientific.net/amr.154-155.701

[6] Shi, G.L., Sun, Y.S., Li, M. et al. Research on control system of 1100 kN crank press driven by AC servo motor. Forging & Stamping Technology, 2009, 34(2):79-82.

[7] James, L. Increasing die life and improving part quality-Factors that affect a stamping press's productivity. The Fabricator, 2000(2):1-3.

[8] Zhou, D.J. Handbook of Forging and Stamping Data, Chinese Mechanical Press, Beijing,1998.

[9] Hongxing Mechanical Co. Ltd, A servo multi-functional crank press and its working manners, Chinese patent, No. 200810026253.0, Publish date: Aug. 6, 20008.

[10] Guangdong Forging & Stamping Machinery Co. Ltd, A servo and precision press, Chinese patent, No. 200720054117.3, publish date: Jun. 11, 2008.

[11] Guangdong Forging & Stamping Machinery Co. Ltd, A triangle-link-knuckle transmission mechanism for servo press with high force gain, Chinese patent, application No. 201010572167.7, application date: Dec. 3, 2010.

[12] Dijksman, E.A. Six-bar cognates of Stephenson Mechanism. Journal of Mechanisms, 6(1971):31-57.

DOI: 10.1016/0022-2569(71)90005-x
