A New System for Dynamic Deflection Measurement of Highway Bridge

Abstract:

The bridge deflection measurement is an important component to the bridge examination and a important target to the security appraises. Using Slope sensor to test the Dynamic deflection is a good way for highway bridge deflection detection. In this paper, we develop a new slope sensor and new theory to fast calculate deflection from slope angle. It has been use to detect the dynamic deflections of songhuajiang bridge on Harbin-Changchuen highway when car cross at kinds of speed. The test result indicates: comparing with the measurement results of photoelectric deflection detection system, the dynamic deflection measurement results of slope sensors are much closed. Their deflection curves are also similar. The result also shows: Using our slope sensors to test highway bridge dynamic deflection can get precise results and can satisfy the highway bridge deflection testing request. It is also very easy to use. You can finish the testing easily and do not stop the traffic.

• Periodical: Applied Mechanics and Materials (Volumes 226-228)
• Pages: 1645-1650
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.226-228.1645
• Online since: November 2012
• Authors: Xian Long He, Tian Li She, Li Zhen Zhao
• Keywords: Deflection Measurement, Dynamic Deflection, Highway Bridge, Photoelectric Deflection Detection, Slope Sensor

References

[1] Zhengxiang Zhao. Comparing with several ways of bridge deflection testing [J]. Road Journal, 1995, 46(7): 20-25.

[2] Xuanshan Yang. Engineering vibration testing and devices technology [M]. Chinese measure journal, 2001.

[3] Charles W.Roeder. Improved live load deflection criteria for steel bridges Report [C]. University of Washington, 2002.

[4] QI Fangxiao. Dynamic Response of Railway [M]. Science and technology press, 2007.

[5] Xuanshan Yang. A new way for bridge deflection testing [J]. Civil engineering journal, 2002, 35(2):92–96.

[6] Xuanshan Yang. The research on transient response of QY slope sensor [J]. Earthquake Engineering and Engineering Vibration, 2002, 22(2):97–100.
