Comparison and Analysis of Permafrost Railway Subgrade Settlement Deformation Monitoring

Abstract:

Under inclement Qinghai-Tibet plateau environment, monitoring and analysis of railway subgrade deformation in plateau permafrost region has very important engineering significance for stability evaluation and safety management. In the paper, satellite interferometry was applied to measure subgrade deformation in the Beiluhe test site along the Qinghai-Tibet railway with gathered satellite interferometric SAR images. Based on the satellite-interferometry-derived data, the deformation characteristics of six points in different permafrost subgrades (the sliced rock embankment, the crushed rock embankment and railway bridge) along the Qinghai-Tibet railway were analyzed and compared. The analysis results show that settlement is the main behavior of railway subgrade deformation and the deformation amount of railway bridge is less than the sliced or the crushed rock embankment along the Qinghai-Tibet railway in permafrost regions.

• Periodical: Applied Mechanics and Materials (Volumes 226-228)
• Pages: 1651-1654
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.226-228.1651
• Online since: November 2012
• Authors: Qu Lin Tan, Chou Xie
• Keywords: Deformation Monitoring, Leveling, Railway Subgrade, SAR Interferometry, Settlement

References

[1] L. X. Zhang: Regularity of ground temperature variation in Qinghai-Tibet Plateau permafrost region and its effect on subgrade stability, China railway science, Vol. 43 (2000) No. 1, p.37.

[2] Ma Wei, Liu Duan, Wu Qingbai. Monitoring and analysis of embankment deformation in permafrost regions of Qinghai-Tibet Railway [J], Rock and soil mechanics, 2008(3): 571-579.

[3] Qulin Tan, Qingchao Wei, Songlin Yang, Discussion on Monitoring Ground Subsidence of Permafrost Roadbed Using Satellite D-InSAR Technology [J], Journal of Railway Engineering Society, 2010, Vol. 27, No. 1. 4-9.

[4] Gabriel A K, Goldstein R Mand Zebker H A. Mapping small elevation changes over large areas: Differential radar interferometry [J]. Geophys. Res., 1989, 94 (B7): 9183~9191.

DOI: 10.1029/jb094ib07p09183

[5] Massonet D, Rossi M C, Carmona , C, et al. The displacement field of Landers earthquake mapped by radar interferometry [J]. Nature, 1993, 364: 138-142.

DOI: 10.1038/364138a0

[6] BERT M. KAMPES, Radar interferometry: Persistent Scatterer Technique [M], Published by Springer (Springer. www. springer. com), (2006).

[7] R. F. Hanssen: Radar interferometry: data interpretation and error analysis (Kluwer Academic Publishers, Dordrecht 2002).

[8] Li Zhen, Li Xinwu, Liu Yong zhi et al. Detecting the displacement field of thaw settlement by means of SAR Interferometry [J], Journal of glaciology and geocryology, 2004, (4): 389-396.

[9] Chou Xie, Zhen Li, Xinwu Li. A Permanent Scatterers Mehtod for Analysis of Deformation over Permafrost Regions of Qinghai-Tibet Plateau [C], Proc. IEEE International Geoscience & Remote Sensing Symposium (Boston, USA, July 6-11, 2008). Vol. 4, p.1624.

DOI: 10.1109/igarss.2008.4779906

[10] Chou Xie, Zhen Li, Ji Xu and Xinwu Li, Analysis of deformation over permafrost regions of Qinghai-Tibet plateau based on permanent scatterers [J], International Journal of Remote Sensing, 2010, 31: 8, 1995-(2008).

DOI: 10.1080/01431160902929255

[11] Tan Qu-lin, Liu Zheng-jun, Yang song-lin, SAR differential interferometry technology and its application to regional deformation surveying: a case study [J]. Journal of civil engineering and architecture, 2008, Vol. 2, No. 1: 73~81.

[12] A. Ferretti, C. Prati and F. Rocca: Permanent Scatteres in SAR Interferometry. IEEE Trans. Geosci. Remote Sensing, Vol. 39 (200l) No. 1, p.8.

DOI: 10.1109/36.898661

[13] Ferretti, A., Prati, C. and Rocca, F. Non-uniform motion monitoring using the permanent scatterers technique[C]. The Second International Workshop on ERS SAR Interferometry FRINGE99, Liege, Belgium, 10–12 November, 1999. ESA. 1–6.

[14] Ferretti, A., Prati, C. and Rocca, F. Permanent scatterers in SAR interferometry [C]. International Geoscience and Remote Sensing Symposium, Hamburg, Germany, 1999, 28 June–2 July, 1–3.

DOI: 10.1109/igarss.1999.772008
