Simulation Analysis of Three-Phase Inverter DC Link Current

Abstract:

The DC link current spectrum has important effects on the active state and life of the battery cell and the bus capacitance in the three-phase inverter. Based on the load of PMSM (Permanent Magnet Synchronous Motor), the DC link current characteristics are presented intuitively using the computer simulation. The paper discusses the method and procedure to the simulation model that includes several key modules: PWM module, inverter module, and PMSM module. The simulating results are presented and analyzed.

• Periodical: Applied Mechanics and Materials (Volumes 229-231)
• Pages: 2015-2018
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.229-231.2015
• Online since: November 2012
• Authors: Guo Qiang Chen, Jun Jie Huang
• Keywords: DC Link Current, Simulation, Space Vector PWM, Three-Phase Inverter

References

[1] Ahmet M. Hava: Carrier based PWM-VSI drives in the overmodulation region. Ph. D dissertation, Univ. Wisconsin, Madison(1998).

[2] Ahmet M. Hava, Russel J. Kerlman, Thomas A. Lipo: Simple analytical and graphical methods for carrier-based PWM-VSI drives. IEEE Transactions on Power Electronics. 14, pp.49-61(1999).

DOI: 10.1109/63.737592

[3] D. Grahame Holmes, Thomas A. Lipo. Pulse width modulation for power converters: principles and practice. USA : IEEE Press; (2003).

[4] Brendan Peter McGrath, Donald Grahame Holmes. A general analytical method for calculating inverter DC-link current harmonics. IEEE Transactions on Industry Applications 2009; 45: 1581~1589.

DOI: 10.1109/tia.2009.2027556

[5] Evans P D, Hill-Cottingham R J. DC Link Current In PWM Inverters. IEE Proceedings B: Electric Power Applications 1986; 133: 217-224.

DOI: 10.1049/ip-b.1986.0030

[6] Hao SH, Tang ZL, Hao MH, Liu J. Vector Control of high speed PMSM based on single-pole magnetic encoder. Journal of Tianjin University 2010; 43: 411-416.

[7] Sun YW. Development and application of the modern PMSM and AC-servo system. Small & Special Electrical Machines 2010; No. 3: 71-73.

[8] Wang XP, Li SY, Huang XD. Design and simulation of PMSM servo system. Science Technology and Engineering 2009; 9: 2907-2911.

[9] Li XJ, Geng LF. Development and application of the modern PMSM&AC-servo system. Electrical Machinery Technology 2009; No. 5: 20-22.

[10] PLECS. http: /www. plexim. com.

[11] Wang CY, Xia JK, Yang JY, Sun YB. Modern motor control technology. Beijing: China Machine Press; (2006).

[12] Chen GQ, Wu ZH, Zhu Y. Development and analysis of unified simulation model for space vector PWM strategies. Commun Comput Info Sci 2011; 144: 230-235.
