Acoustic Information Acquisition and Time Domain Analysis on Alternating Current Rail Flash Butt Welding

Abstract:

Based on the mobile rail flash butt welding machine UN5-150ZB, the synchronous data acquisition hardware system was designed to collect welding current, welding voltage and flash acoustic signal in welding process, and the software platform with the functions of signal collecting, waveform display and data operation was developed by higher-level programming language LabVIEW. After the welding current, welding voltage and flash acoustic signal in welding process had been collected, the mean, variance and mean square value of flash acoustic signal in time-domain were analyzed. Through comparison, the relationship between these characteristics and the stability of flash was analyzed. The result shows that the changes of mean and variance of flash acoustic signal are not obvious, and do not correlate with stability of flash, but the mean square value in time domain is closely associated with the stability of flash, and the stability of flash can be indicated by the mean square value.

You might also be interested in these eBooks

Measurement Technology and its Application

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 239-240)

Pages:

16-20

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.239-240.16

Citation:

Cite this paper

Online since:

December 2012

Authors:

Qi Bing Lv, Ke Li Tan, Xi Zhang, Jian Chen, Guo Qing Liu

Keywords:

AC Flash-Butt Welding, Acoustic Signal, Flash Stability, LabVIEW

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] LV Qibing Et Al. Quality Prediction Of Alternating Current Flash Butt Welding Of Rail Based On Improved Back Propagation Neural Network. Welding Journal, 2005, 26(5): 65-68.

Google Scholar

[2] LV Qibing, TAN Keli, LUO Deyang. Prediction Of Area Of Gray-Spots Flaw In Alternate Rail Flash Butt Welded Joint Based On RBF Neural Network. Welding Journal, 2008, 29(2): 93-96.

Google Scholar

[3] LV Qibing Et Al. Extract And Analyze Welding Quality Characteristic Of AC Rail Flash Butt Welding With High-Speed Sampling. Electric Welding Machine, 2005, 35(5): 26-29.

Google Scholar

[4] YANG Leping, LI Haitao, ZHAO Yong Et Al. High Level Programming Labview [M]. Beijing: Tsinghua University Press, 2003.

Google Scholar

[5] GAO Long. Research On Tool Wear Monitoring Techniques Based On Wavelet Analysis And Integrated Neural Network. Southwest Jiaotong University Master Thesis, 2007.

Google Scholar
