Algorithm Research on Tower Grounding Resistance On-Line Measurement

Abstract:

Traditional transmission line tower grounding resistance measurements have many shortcomings, in order to make up the defects the model of transmission line tower with good conductor wires and multiple grounding leads was builded, and then the algorithm of tower grounding resistance on-line measurement was proposed. On this condition, a system based on this algorithm was designed and further analysis of the error during data processing was conducted. At last, the MATLAB simulation indicates that the algorithm has a accuracy that meets the practical requirements.

• Periodical: Applied Mechanics and Materials (Volumes 239-240)
• Pages: 372-375
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.239-240.372
• Online since: December 2012
• Authors: Tao Wang, Bing Li, Hong Xing Yang
• Keywords: Error Analysis, Grounding Grid, Grounding Resistance, Transmission Line Tower

References

[1] LIU Zesheng, XU Jiakui: High Voltage Engineering. Vol. 27(2001) , pp.27-28.

[2] DL/T 596-1996: Preventive test code for electric power equipment (CHINA ELECTRIC POWER PRESS, CHINA, 1996).

[3] DL/T 741-2001: Operating code for overhead transmission line. (CHINA ELECTRIC POWER PRESS, CHINA, 2001).

[4] XU Hua, WEN Xishan, HUANG Ling: High Voltage Engineering. Vol. 32(2006), pp.79-81.

[5] ZHANG Qihua: HIGH VOLTAGE ENGINEERING. Vol. 33(2007), pp.194-195.

[6] LUO Zhenhai, CHEN Xiongyi, XIAO Dinghui: Electric Power. Vol. 30(1997), pp.70-71.
