Methods of Dynamic Tire Pressure Judgment Based on Image Processing

Abstract:

When car is in the process of high-speed, the faults caused by tire pressure anomalies are the most worried and difficult to prevent for all drivers. It is one of the important reasons for the sudden traffic accidents. Tire pressure related to ride comfort, fuel consumption, tire wear and vehicle safety, so tire pressure’s monitoring has been one of the important research directions in the safe driving of vehicle. The anomalies of tire pressure made the vehicles appear to tilt and shorten the distance between rim centres and the ground. Using image technology can detect intuitively and fast. This paper measures the dynamic tire pressure based on image processing technology. The vehicles tires goal was extracted by three image differences. After morphological processing, it used three methods to make comprehensive analysis and judgement of whether the tire pressure is normal, to realize the automation and intelligence. This method had realized real-time non-contact detection for dynamic tire pressure, which has extended significance to popularize.

• Periodical: Applied Mechanics and Materials (Volumes 239-240)
• Pages: 980-985
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.239-240.980
• Online since: December 2012
• Authors: Rong Bao Chen, Jun Jie Zhang, Hua Feng Xiao, Fang Hui Meng
• Keywords: Dynamic Tire Pressure, Image Processing, Non-Contact Detection

References

[1] Chao Lin and Yong Lei. Design of Car Tire Pressure Monitoring System Based on ARM and wireless Sensor[J] 2011 Computer Measurement & Control. 19 283

[2] Yu Huang. It's Early to Force the Installation of TPMS[N] 2010-10-18 Commercial Vehicle News. 12

[3] Janjun Tan and Tianfa Jiang. A Pinhole Camera-based Tire Pressure Detection Device[J] 2004 Journal of Wuhan University of Technology (Transportation Science & Engineering). 3 388-90

[4] Rongbao Chen, Jing Tao, Wuting Fan and Junjie Zhang. Research on Methods of Tire Sensory Measurement Based on Image Processing[J] 2011.6 Advanced Materials Research. 1 900- 04

DOI: 10.4028/www.scientific.net/amr.230-232.900

[5] Xihan Zhou, Bo Liu and Heqin Zhou. A Motion Detection Algorithm Based on Background Subtraction and Symmetrical Differening[J] 2005 Computer simulation. 4 117-20

[6] Guoliang Lv, Shuguang Zhao and Jun zhao. Novel Method of Moving Object Detection Based on Three Frame Differencing and Connectivity Checking[J] 2007 Chinese journal of Liquid Crystals and Displays. 22 87-93

[7] Yanping Chen. Moving Target Detection Algorithm Based on Background Subtraction[D]. Xiamen: Xiamen University, 2008:2
