Research on the Mechanism of Multi-Source Piezoelectric Vibratory Feeder

Abstract:

Vibration feeder is the device of subsequent orientation feeding using vibration for the granular or power materials. This device could be used in food, medicine, chemistry and so on. We announce the phenomenon of materials handling based on testing and analyzing the granular materials in the multi-source piezoelectric vibratory feeder. The results show that the vibratory spreads is the traveling wave in this device, when the device is operated. The elastic particle is the elliptic movement at the end of the stuff box. The dynamic of material movement mainly come from the traveling wave caused by particle elliptical movement, the destruction to the grain’s natural balance status caused by the vibration and the geometric position-limit guiding structure of the device and so on.

• Periodical: Applied Mechanics and Materials (Volumes 241-244)
• Pages: 1427-1430
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.241-244.1427
• Online since: December 2012
• Authors: Yang Wang, Wen Fu Wu, Su Ping Shi
• Keywords: Compound Movement, Mechanism, Piezoelectricity, Vibratory Feeder

References

[1] Zhang Xiliang, Lu Xin, Mao Cuiyun. Study on the Techniques of Composite Type Quantifying-Filling for Powder and Particle Materials[J]. Acta Metrologica Sinica, 2003, 24(4): 310-313. (In Chinese).

[2] Deng Mingcheng. Newly Organized College Physics[M]. Science Press, 2002, The second published, 79-109. (In Chinese).

[3] Jiang Xinger. Research on the feasibility and driving model of ultrasonic traveling wave micro-fluid driving and controlling technique[D]. Shandong: Shandong University, 2006. (In Chinese).

[4] Tian Zhongjing, Wu Wenfu, Han Feng. The Experimental Research on the Floating Piezoelectric Vibratory feeder[J]. Piezoelectricity and Acousto-optic, 2006, 28(5): 557-559. (In Chinese).

[5] Shi Suping. Research on the Multi-point Piezoelectric Vibratory Feeder and the Control System[D]. Jilin: Jilin University, 2007. (In Chinese).

[6] S.B. Choi, D.H. Lee. Modal analysis and control of a bowl parts feeder activated by piezoelectric actuators[J]. Journal of Sound and Vibration, 2004, 275(3): 452-458.

DOI: 10.1016/j.jsv.2003.10.008
