Improved Analytic Guidance Algorithm for Mars Entry

Abstract:

With the development of Mars exploration, NASA has been preparing plans for a crewed mission to Mars in the next few decades. One challenge associated with crewed missions to the Mars is the high ballistic-coefficient and human-class payloads. Because of the high ballistic-coefficient, the maximum limit value of the reference flight path angle is always the reference flight path angle meeting the downrange and altitude for the constant flight path angle algorithm. So this paper presents an improved algorithm which the terminal velocity is controlled by dynamic pressure controller, and the controller is used to modulate the velocity and altitude to meet final constraints. Simulations results of a Mars entry scenario illustrate that the improved algorithm achieves the final constraints within allowable tolerances.

• Periodical: Applied Mechanics and Materials (Volumes 241-244)
• Pages: 1400-1405
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.241-244.1400
• Online since: December 2012
• Authors: Hong Ying Xu, Hu Tao Cui
• Keywords: Analytic Guidance, Dynamic Pressure Controller, High Ballistic Coefficient, Mars Entry

References

[1] R.D. Braun, R.M. Manning: Mars Exploration Entry, Descent, and Landing Challenges. J. Spacecraft and Rockets. Vol. 44 (2007), pp.311-323

DOI: 10.2514/1.25116

[2] Z. Khan, J.A. Hoffman: Key Directions for Entry, Descent and Landing Research for Crewed Mars Missions. AIAA Space Conference & Exposition. California, (2009)

DOI: 10.2514/6.2009-6611

[3] B.A. Steinfeldt, M.J. Grant, D.A. Matz, and R.D. Braun: Guidance, Navigation, and Control System Performance Trades for Mars Pinpoint Landing . J. Spacecraft and Rockets. Vol. 47 (2010), pp.188-195

DOI: 10.2514/1.45779

[4] J.A. Christian, G. Wells, J. Lafleur, A. Verges, and R.D. Braun:Extension of Traditional Entry, Descent, and Landing Technologies for Human Mars Exploration. J. Spacecraft and Rockets. Vol. 45, (2008), pp.132-140

DOI: 10.2514/1.31929

[5] J.L. Davis, A.D. Cianciolo:Guidance and Control Algorithms for the Mars Entry,Descent and Landing Systems Analysis. AIAA Guidance, Navigation, and Control Conference. Toronto,(2010)

DOI: 10.2514/6.2010-7972

[6] D.L. Jean, L. Jean, K. Aymetric: Robust Guidance and Control Algorithms using Constant Flight Path Angle for Precision Landing on Mars. AIAA Guidance, Navigation, and Control Conference and Exhibit, Colorado, (2006)

DOI: 10.2514/6.2006-6075

[7] T.A. Dierlam: Entry Vehicle Performance Analysis and Atmospheric Guidance Algorithm for Precision Landing on Mars. S.M. Thesis. United States Air Force Academy (1990), pp.90-100
