Analysis on Geometry Error Software Compensation Technology Model of Gantry Five-Axis NC Machine Tool

Abstract:

Based on multi-body system, the error model of gantry five-axis NC machine tools was discussed. The calculate method of precision process equation and NC instruction has been derived out. Based the above research works，make a emulate by using of geometry error compensation soft-ware. The result show machining precision can be improved through the error compensation method which is concluded in this paper.
