A High-Speed and High-Linearity BiCMOS Optically Coupled Isolation Amplifier

Abstract:

To improve the current non-linear optically coupled isolation amplifier and high power consumption, we designed a low-power, high-speed and high-linearity BiCMOS optically isolation amplifier. There are only two push-pull output stages configuration bipolar transistor (BJT) in the design process, the rest of the circuit is the CMOS device. To improve amplifier gain linearity and stability, we introduce the complementary symmetrical photodiode, in the optically coupled part and every amplifier, negative feedback is introduced. Experimental results indicate that the design of optically isolation amplifier ± 3 dB bandwidth increases 40 kHz than optically isolation amplifier ISO100 bipolar, When the power supply voltage is 4.8 V, the delay - power product of DP is lower than ISO100 37.3 pJ, gain linearity is up to 5.5 × 10-5, which is suitable for high-speed control system.

• Periodical: Applied Mechanics and Materials (Volumes 241-244)
• Pages: 2200-2203
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.241-244.2200
• Online since: December 2012
• Authors: Shu Han Li, Ning Yang, Li Cheng, Sheng Hua Zhang
• Keywords: BiCMOS Device, Delay-Consumption Product, High-Speed Control System, Optically Coupled Isolation Amplifier

References

[1] Olschewski B. Optical coupling extends isolation-amplifier utility. Electronics, vol. 49(18), 1976, pp.81-88.

[2] Smith G C. Channel electron multiplier and optically coupled amplifier used as an incident flux monitor. Nuclear Instruments and Methods in Physics Research, Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, vol. 222(2), 1983, pp.262-265.

DOI: 10.1016/0167-5087(84)90541-6

[3] Gaggini G, Manfredi P F, Maranesi P, et al. Isolation amplifier with combined magnetic and optical coupling. IEEE Transactions on Instrumentation and Measurement, vol. 24(2), 1975, pp.115-117.

DOI: 10.1109/tim.1975.4314390

[4] Cheng L, Yang N, Zhou X D, et al. A novel low power consumption and quasilinear CMOS optically coupled isolation amplifier. 2010 International Conference on Computer, Mechatronics, Control and Electronic Engineering, CMCE 2010, vol. 5, 2010, pp.175-178.

DOI: 10.1109/cmce.2010.5610001
