Design of Intelligent Display Meter Based on ARM

Abstract:

Display meter is the basic unit of automation system. In order to improve the performance and the compatibility of display meter, a design of intelligent display meter based on ARM is put forward. The Micro Control Unit (MCU) STM32F103VE based on the 32 bit ARM Cortex–M3 core is used as the host controller of the meter system. On the basis of this controller, hardware and software design were carried out. The intelligent display meter can receive voltage and current signals from most sensors. Because of the excellent processing capability and rich peripherals of the MCU, the meter can handle large amounts of data rapidly so as to monitor the status of industrial field in real time and communicate with different upper computers.

• Periodical: Applied Mechanics and Materials (Volumes 241-244)
• Pages: 525-528
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.241-244.525
• Online since: December 2012
• Authors: Ke Gan, Xi Wei Peng, Zhan Dong Zhao
• Keywords: Cortex-M3, Intelligent Meter, Modbus, STM32F103

References

[1] Songlin Zhuang, Zhonghan Xiao: Process Automation Instrumentation Vol 30 (2009).

[2] Yongkang Zhang, Wenhai Wang, Youxian Sun: Journal of Zhejiang University (Engineer Science) Vol 34 (2000)

[3] Gang Peng, Zhiqiang Chun, in: Practice of Embedded Microcontroller STM32 based on ARM Cortex-M3, "In Chinese", Electronics Industry Publishers (2011)

[4] Reference manual: STMF101xx, STM32F102xx, STM32F103xx, STM32F105xx and STM32F107xx advanced ARM-based 32 bit MCUs. RM0008. ST Microelectronics Limited (2010)

[5] Liang Wang, Control & Automation Vol 24 (2008)

[6] Zhanming Guan, Yanping Gao: Hydraulic Science and Technology Vol 26 (2004)

[7] Qianjun Xiao: Manufacturing Automation Vol 32 (2010)
