Design Square Grid Sandwich Plate Based on Equivalent Theory

Abstract:

A square grid sandwich plate is modeled as a laminate plate in this paper, and the equivalent method is proved according to natural frequencies of the grid sandwich plate and the equivalent plate. Effects of geometric and material parameters on the equivalent Young’s modulus, equivalent thickness, and equivalent density are discussed and some conclusions are obtained:(1) effects of thickness of upper and lower panels on equivalent parameters are the same; (2) keeping the total thickness of upper and lower panels a constant, the equivalent thickness reaches its maximum while thickness of upper panel is equal to that of lower panel, meanwhile the equivalent Young’s modulus and equivalent density get to their minimum values; (3) the equivalent thickness and density increase with thickness of grid sandwich core; (4) the equivalent Young’s modulus decreases while the thickness of grid sandwich core increases; (5) the equivalent Young’s modulus increases with that of the grid core; (5) the equivalent density is inversely proportional to the equivalent thickness; (6) the equivalent Young’s modulus is inversely proportional to the equivalent thickness. These conclusions are helpful to design square grid sandwich plate.

• Periodical: Applied Mechanics and Materials (Volume 248)
• Pages: 365-369
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.248.365
• Online since: December 2012
• Authors: Jin Tao Gu, Mei Ping Sheng, Fei Han
• Keywords: Design Parameter, Equivalent Theory, Square Grid Sandwich Plate

References

[1] Vasiliev V V, Barynin V A, Rasin A F, Anisogrid lattice structures survey of development and application. Composite Strutures, 54(2001) 361-370.

DOI: 10.1016/s0263-8223(01)00111-8

[2] Hou A, Gramoll K, Design and fabrication of CFRP interstage attach fitting for launch vehicles. Journal of Aerospace Engineering , 12(1999)83-91.

DOI: 10.1061/(asce)0893-1321(1999)12:3(83)

[3] Ralph E L, Linder E B, Advanced solar panel designs Advanced solar panel designs. Conference Record of the IEEE Photovoltaic Specialists Conference, (1996)297~300.

DOI: 10.1109/pvsc.1996.564004

[4] Fan Hualin, Jin Fengnian, Fang Daining. Structural mechanics of lattice grids. Advanced in Mechanics, 38(2008)35-52.

[5] Gou Wenxuan, Mechanics of Materials, 1st ed, Science Press, (2005).

[6] Fu Liying, Wang Weiyang, Equivalent Calculation and Experiment Research on the Honeycomb Sandwich Plates Used in Satellite. Science Technology and Engineering. 8(2008)6429-6432.

[7] Xia Lijuan, Jin Xianding, Wang Yangbao, Equivalent Analysis of Honeycomb Sandwich Plates for Satellite Structure. Journal of Shanghai Jiaotong University. 37(2003)999-1001.

[8] Zhai Guang, Yang Xiaoping, Liang Bin, Li Cheng, Modal analysis of multi-interlayer honeycomb plate. Journal of Mechanical Strength. 29(2007)517-520.

[9] Zhang Tieliang, Ding Yunliang, Jin Haibo, Comparative analysis of equivalent models for honeycomb sandwich plates. Chinise Journal of Applied Mechanics. 28(2011)275-282.

[10] Fu Minghui, Yin Jiuren. Equivalent elastic parameters of the honeycomb core. Acta Mechanica Sinica, 31(1999)113-118.

[11] Gibson L J, Ashby M F, Schajer G S, et al. The mechanics of two-dimension cellular materials. Proceedings of the Royal Society of London Series A, 382(1982) 25-42.
