The Mechanism of Quasi-Dynamic Expansion Method and the Design of the Equipment for Manufacturing Biaxial Oriented PVC Pipes

Abstract:

Biaxial oriented PVC (PVC-O) pipes have great advanced properties: high intensity, high impact resistance, material saving etc. The new product can be used in many situations. There are more than three effect methods for manufacturing PVC-O pipes in foreign countries. Relevant researches have been preceded in some domestic institutes, but there are no effect processing methods and productive technologies have been reported. Based on plastics bulge forming and hop-pocket method, the quasi-dynamic continual expansion method (QDCE) is proposed in the paper. The key point of QDCE takes advantage of high elasticity、high compression ratio and high tear resistance of elastomeric materials, meanwhile designs production equipment and processing technology for manufacturing PVC-O pipes. We explore the mechanism of QDCE and design a whole package of expanding equipment.

• Periodical: Applied Mechanics and Materials (Volume 248)
• Pages: 387-390
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.248.387
• Online since: December 2012
• Authors: Guang Jun Song, Da Ming Wu, Ying Liu, Hui Jiang, Xin Zhang
• Keywords: Biaxial Oriented, Elastomer, Equipment Design, Mechanism, PVC-O, Quasi-Dynamic Continual Expansion Method (QDCE)

References

[1] P.G. Chapman, L. Ågren. New technology for in line manufacturing of biaxially oriented poly (vinyl chloride) pipes [J]. Plastic and Rubber Processing and Application. 1998, 27(10): 452-459.

[2] A.K. Taraiya and I.M. Ward. Biaxially oriented polymer tubes by die drawing [J]. Plastic, Rubber and Composites Processing and Application, 1996, 25(6): 287-290.

[3] Abdellah Ajji, Kenneth, C. Cole, Michel, M. Dumoulin, I.M. Ward. Roll-drawing and die-drawing of initially amorphous PET[C]. ANTEC'97, 1707-1711.

[4] P.G. Chapman, L. Ågren. New technology for in line manufacturing of biaxially oriented poly (vinyl chloride) pipes [J]. Plastic and Rubber Processing and Application. 1998, 27(10): 452-459.

[5] Zhang Yuchuan. To create new situation for pvc pressure pipes system [C]. Cyclic economy and new technology of plastics processing. 2006: 1-18.

[6] He Yadong, Li Song, Zhu Fuhua. Theoretical study for plastic bulge forming processing [J]. Plastic. 2003, 32(5): 34-40.

[7] He Yadong, Li Huiling, Zhu Fuhua. Finite element simulation of plastic bulge forming processing [J]. Plastic. 2004, 33(1): 82-85, 44.

[8] Dong Weiyu, Ren Dongyun, Zhang Bo, Wu Daming. The theoretical calculation and experiments of cloth-tube method for manufacturing PVC-O pipes [J]. Plastic. 2009, 38(4): 76-78.
