Slip-Slope Estimation of Mutative Road Friction Coefficient Based on Unscented Particle Filter

Abstract:

The accurate information of road friction coefficient allows the control algorithm in vehicle activity system to adapt to external driving conditions. This paper developed a slip-slope friction coefficient estimation method based on Unscented Particle Filter. A 7-DOF non-linear vehicle dynamic model was established. The normal force of tire was approximately calculated from the vehicle dynamic model; the slip and longitudinal force of tire were estimated through a combination of tire mechanical model and UPF(Unscented Particle Filter) method. Finally slip-slopes of different adhesion level roads was obtained. Through virtual test environment in ADAMS/Car, the estimation method proposed was verified to be effective and reliable under various road condition. From the method the relationships between the slip-slope and road friction coefficient are achieved.

• Periodical: Applied Mechanics and Materials (Volumes 249-250)
• Pages: 337-342
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.249-250.337
• Online since: December 2012
• Authors: Fen Lin, Chao Huang
• Keywords: Estimation, Friction Coefficient (FC), Slip-Slope, Unscented Particle Filter, Virtual Test

References

[1] Changsun Ahn , Huei Peng , H Eric Tseng. Robust estimation of road friction coefficient. Proceedings of the American Control Conference, San Francisco, CA 2011, 3948-3953.

DOI: 10.1109/acc.2011.5991256

[2] F Gustafsson. Estimation and Change Detection of Tire-road Friction Using the Wheel Slip. Proceedings of the IEEE International Symposium on Computer-Aided Control System Design, 1996: 99-104.

DOI: 10.1109/cacsd.1996.555237

[3] K. Yi, K. Hedrick, S. C. Lee. Estimation of tire-road friction using observer based identifiers. Vehicle Syst. Dyn, 1999, 31: 233–261.

DOI: 10.1076/vesd.31.4.233.4231

[4] W Hwang, B Song. Road condition monitoring system using tire-road friction estimation. Proceedings of AVEC, Michigan, (2000).

[5] S Müller, M Uchanski, K Hedrick. Estimation of the Maximum Tire-Road Friction Coefficient. Journal of Dynamic Systems, Measurement, and Control, 2003, 125: 607 - 617.

DOI: 10.1115/1.1636773

[6] R Rajamani, P Damrongrit, J Y Lew, et al. Tire-Road Friction-Coefficient Estimation. IEEE Control Systems Magazine, 2010: 54 – 69.

[7] J M Wang, A Lee, R Rajamani. Friction Estimation on Highway Vehicles Using Longitudinal Measurements. Journal of Dynamic Systems, Measurement, and Control, 2004, 126 (6) : 265 - 275.

DOI: 10.1115/1.1766028

[8] U Kiencke, L Nielsen. Automotive Control Systems. Berlin: Springer, (2000).

[9] E Bakker, H B Pacejka. A New Tire Model with An Application in Vehicle Dynamics Studies. SAE Paper 890087.

DOI: 10.4271/890087

[10] E A Wan, A T Nelson. Kalman Filtering and Neural Networks. New York: John Wiley & Sons, (2001).
