Finite Element Analysis of Anchor Assembly in Cable Hydraulic Lift

Abstract:

The anchor assembly is the important part of the hydraulic lift, the stresses of which under load are analyzed using finite element method. The 3D mechanical models of anchor assembly are created with different sizes. Several important positions are investigated around the holes of upper anchor and these stresses are compared between different cases. Based upon the numerical results, the safety assessment of the anchor assembly is conducted and a reasonable design scheme is proposed.
