Prediction Model Establishment of the Opening Angle of a Ball Valve

Abstract:

In this paper, the characteristics of a two-way ball valve orifice are researched. By means of modeling and analyzing of the trajectory of valve opening angle, a conclusion was drawn that there was trigonometric function relationship between the orifice area and opening angle of a ball valve. Based on this, the bench tests are conducted with the spraying system with 6 nozzles. It can be seen that there is a good agreement between prediction model established and experiment by the method of border points checking, the absolute error is in the range of 0~0.002mm2. With further research, there is a marked logarithmic relationship between the orifice area of a ball valve and flow of the sprayer, the correlation coefficient is 0.9952.

• Periodical: Applied Mechanics and Materials (Volumes 260-261)
• Pages: 570-575
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.260-261.570
• Online since: December 2012
• Authors: Zhan Rong Feng, Li Xia Wang, Zheng Quan Li
• Keywords: Logarithmic Relationship, Mathematical Modeling, Two-Way Ball Valve

References

[1] Han Liren. Pipeline and Valve [M]. Beijing: Water Resources and Electric Power Press, (1988).

[2] Chen Kuisheng, Hydraulic Pressure and Pneumatic Transmission [M]. Wuhan: Wuhan University of Technology Press, (2001).

[3] Mo Bin. Process Control Engineering [M]. Beijing: Chemical Industry Press, (1991).

[4] He xiao-feng, Huang guo-qin, Yang you-sheng, et al. Expire Entail Research on the flow characteristics of ball valve orifice. Cinese Journal of Mechanical Engineering. 2004, 40(8): 30~33.

[5] Zheng jian-guang, Liu chang-hai. Experimental investiga- tion of discharge characteristic of electrical ball valve. Valve, 2005, (1): 17~19.

[6] Shen xin-rong, Pan kang, Shan li-jun, et al. Numerical Analysis and Experimental Investigation of the Control Ball Valve. Fluid Power Transmission and Control, 2008, 1: 6~8, 11.

[7] Gao wen-kai, Liang zheng, Zhong gong-xiang, et al. The mathematical model and computer simulation for the movement of the self-acting ball valve in the reciprocating pump. Oil Field Equipment, 2006, 35(1): 5~9.

[8] Liu gang, Fang jin-chun, Yong qi-wei. The numerical simulation of the regulate valve's dynamic characteristics in long pipeline. Valve. 2004, (4): 8~10, 14.

[9] Yang Ji-we. Research of the Theory of Regulators Flow Adjusting. Fluid Machinery, 2003, 31(2): 24~26.

[10] Qu Shi-lin, Wu Yue-bin, Zhao Hong-bin. Study on Flow Adjustment Characteristic of Valves in Water Distribution System. Fluid Machinery, 2003, 31(11): 16~18, 32.

[11] Wang Xinkun. Commonly used of mathematical formula [M]. Chongqing: Chongqing Press, (1991).

[12] Liu Chongkan. Multivariate function and Calculus of Higher Mathematics(Vol. 2)[M]. Beijing: Central Radio TV University Press, (1999).
