Effect of the Sputtering Presser on Structural and Optoelectrical Properties of ZnO: Ga Films Deposited on Flexible Substrates by DC Magnetron Sputtering

Abstract:

Transparent conducting Ga-doped ZnO (ZnO∶Ga) thin films with high transparency and relatively low resistivity have been successfully prepared on ZnO-buffered Polyimide (PI) by DC magnetron sputtering at room temperature. Structural, morphological, stress, optical and electrical proerties of ZnO∶Ga films are investigated. Experimental results show that all the deposited films are polycrystalline with a hexagonal structure and a preferred orientation perpendicular to the substrates along the c-axis. Sputtering pressure plays an important role on the electrical resistivity of flexible ZnO∶Ga films. When sputteting pressure increases from 2 Pa to 6 Pa, the resistivity of the deposited films initially decreases and then slightly increases. At the optimum sputtering pressure of 4 Pa, the lowest resistivity of 4.3×10-4Ω•㎝ is obtained. All the filma present a high transmittance over 90％ in limit spectral range.

• Periodical: Applied Mechanics and Materials (Volumes 263-266)
• Pages: 90-94
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.263-266.90
• Online since: December 2012
• Authors: Xiao Li Wu, Yu Zhen Yuan, Han Fa Liu, Yun Yan Liu
• Keywords: DC Magnetron Sputtering, Flexible Substrat, PI, Sputtering Presser, Transparent Conducting Film, ZnO:Ga Film

References

[1] Yang T L, Zhang D H, Ma J, et al. Transparent conducting ZnO:Al films deposited on organic substrates deposited by RF magnetron-sputtering [J].Thin Solid Films, 1998, 326(1/2): 60－62.

DOI: 10.1016/s0040-6090(98)00763-9

[2] Lu yun-hua, Kang wenjuan, Hu zhi-zhi, etc. substrate materials of flexible transparent conductive films, New Chemical Materilals. Vol-38, 2010(27-29).

[3] Li su-min, Zhao yu-tao, Zhan-zhao, structure and properties of Zno: Ga films deposition in flexible substrates by magnetron sputtering, Solar Technology (2007)11-1233-06.

[4] Dong-Ho Kim; Mi-Rang Park; Hak-Jun Lee Thickness dependence of electrical properties of ITO film deposited on a plastic substrate by RF magnetron sputtering 2006(02).

DOI: 10.1016/j.apsusc.2005.12.097

[5] Zhang H F, Yuan Y Z, Liu H F, Flexible transparent conductive ZnO:Al film. Semiconductor Technology. 2008, 33(6): 461-465.

[6] ZHANG Hua-fa, LEI Cheng-xin，LIU Han-fa, YUAN Chang-kun, A novel transparent conducting ZnO：Zr films deposited on ZnO-buffered flexible Substrates by D C M agnetron Sputtering, Journal of synthetic crydtals, Vol,38, 2009: 732-737.

[7] Quan-Bao Ma, Zhi-Zhen Ye, Hai-Ping He, Li-Ping Zhu, Bing-Hui Zhao, Effects of deposition pressure on the properties of transparent conductive ZnO:Ga films prepared by DC reactive magnetron sputtering, Materials Science in Semiconductor Processing 10 (2007) 167–172.

DOI: 10.1016/j.mssp.2007.11.001

[8] X. Bie, J.G. Lu*, L. Gong, L. Lin, B.H. Zhao, Z.Z. Ye, Transparent conductive ZnO:Ga films prepared by DC reactive magnetron sputtering at low temperature, Applied Surface Science 256 (2009) 289–293.

DOI: 10.1016/j.apsusc.2009.08.018

[9] Shi Z L, Liu D l, Yan X L, et al Low temperature buffer layer on the quality of ZnO thin films[ J ], Chinese journal of luminescence, 2008, 124
