Simulation of Power Transformer Windings Displacement Caused by Multiple Short-Circuit Forces

Abstract:

This research studies the displacement on the windings of transformer due to multiple short-circuit forces. The power transformer winding deformations cumulative impact of multiple short-circuits are studied. the cumulative impact of multiple short-circuit deformation of laminated cylindrical shell with stiffeners model is established, the impact of accumulated deformation of multiple short-circuit of transformer winding is calculated with large deformation elastic-plastic theory , the text introduced by the theoretical formula for power transformer windings of the elastic-plastic deformation analysis of and winding to determine the stability have great significance, To verify the computation results, they are compared with those obtained using ANSYS software simulation.

• Periodical: Applied Mechanics and Materials (Volumes 268-270)
• Pages: 1341-1344
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.268-270.1341
• Online since: December 2012
• Authors: Hong Kui Li
• Keywords: Displacement, Finite Element Method (FEM), Force, Multiple Short-Circuit, Power Transformer

References

[1] Brunke J.H.and K.J. Frohlich, "Elimination of transformer inrush currenta by controlled switching, "Theoretical considerations.IEEETrans.Power Delivery, Vol.16,No.2, pp.276-280, (2001)

DOI: 10.1109/61.915495

[2] Adly, A.A., "Computation of inrush current forces on transformer windings",IEEE Trans.Magn., Vol.37, pp.2855-2857, 2001.

DOI: 10.1109/20.951327

[3] Arturi, C.M. Force calculation in transformer windings under unbalanced mmfs by a nonlinear finite-element code. IEEE Trans. Magn., Vol.28 (2)，pp.1363-1366， 1992.

DOI: 10.1109/20.123945

[4] D. Dolinar, J. Pihler, and B. Grcar, "Dynamic model of a threephase power transformer," IEEE Trans. Power Del., vol. 8, no. 4, p.1811–1819, Oct. 1993.

DOI: 10.1109/61.248289
