Performance Characterization of the Novel Topology for High-Frequency Isolation Bi-Directional DC/DC Converter

Abstract:

A novel topology of high-frequency isolation bi-directional DC/DC converter used in high-Input low-output system was proposed, which has not only the advantages, such as enabling bidirectional power flow, ease of realizing soft-switching control, galvanic isolation, high reliability and so on, but also can be used in high-input voltage application and apparently decreases the stress of the switches, which reduces the cost of the converter, improves power density and the efficiency of the converter. According to the different work condition, two control strategies are analyzed in this paper: the traditional phase shifting control (TPC) and PWM plus phase shifting control (PPC), which further improves the overall efficiency of the converter. The MATLAB simulation has been done to verify the feasibility of the proposed DC/DC converter and accuracy of the criterion.

• Periodical: Applied Mechanics and Materials (Volume 273)
• Pages: 305-309
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.273.305
• Online since: January 2013
• Authors: Peng Hui Jing, Cong Wang, Jun Wang, Feng Zhao
• Keywords: Control Strategy, High-Frequency Isolation Bi-Directional DC/DC Converter, Soft Switching, Three-Level Half Bridge

References

[1] Haifeng Fan, Hui Li.: A novel phase-shift bidirectional DC-DC converter with an extended high-efficiency range for 20 kVA solid state transformer. In: Energy Conversion Congress and Exposition (ECCE), IEEE(2010)3870 - 3876.

DOI: 10.1109/ecce.2010.5617771

[2] Hui Li, Peng, F.Z., Lawler, J.S.: A natural ZVS high-power bi-directional DC-DC converter with minimum number of devices. In: Industry Applications Conference, 2001. Thirty-Sixth IAS Annual Meeting. Vol. 3, p.1874 – 1881.

DOI: 10.1109/ias.2001.955786

[3] Byeong-Mun Song, Bushnell, A., Ennis, J.: A three-level DC-DC converter with wide-input voltage operations for ship-electric-power-distribution systems. In: Plasma Science, IEEE Transactions on Issue(2004). Vol: 32, Issue: 5, p.1856 – 1863.

DOI: 10.1109/tps.2004.835485

[4] Lee, I. -O. , Moon, G. -W.: Analysis and Design of a Three-Level LLC Series Resonant Converter for High- and Wide-Input-Voltage Applications. In: Power Electronics, IEEE Transactions on Issue, Vol. 27, Issue: 6 pp.2966-2979, June (2012).

DOI: 10.1109/tpel.2011.2174381

[5] Mishima, T., Sugimura, H., Sayed, K.F., Kwon, S.K. , Nakaoka, M.: Three-level phase-shift ZVS-PWM DC-DC converter with high frequency transformer for high performance arc welding machines. In: Applied Power Electronics Conference and Exposition (APEC), 2010 Twenty-Fifth Annual IEEE Issue, p.1230.

DOI: 10.1109/apec.2010.5433344

[6] R. W. A. A. De Doncker, D. M. Divan, and M. H. Kheraluwala.: A three-phase soft-switched high-power-density dc/dc converter for high power applications. In: IEEE Trans. Ind. Appl., vol. 27, no. 1, p.63–73, Feb. (1991).

DOI: 10.1109/28.67533
