Research on Linear Array TDI-CCD System with Noise Suppression

Abstract:

Noises in the imaging process will result in image measurement errors, so whether these noises can be effectively suppressed is the key to improve the measurement accuracy. This paper analyzes the noise components of TDI-CCD system from three perspectives, builds the mathematical model of typical noises, designs correlated double sampling noise processing circuit for TDI-CCD system, realizes the software implementation of hardware design and achieves the purpose to improve the signal-to-noise ratio and image quality

• Periodical: Applied Mechanics and Materials (Volume 274)
• Pages: 266-269
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.274.266
• Online since: January 2013
• Authors: Ke Ming Li, Chao Zhang
• Keywords: Linear Array, Noise Suppression, TDI-CCD

References

[1] E Banghart, J Lavine, E Trabka, E Nelson, B Burkey. A model for charge transfer in buried-channel charge-coupled devices at low temperature [J]. IEEE Trans. Electron Device, (1991), 38(5): 1162-1174.

DOI: 10.1109/16.78394

[2] Irie K, McKinnon A E , Unswort h K, et al . A technique for evaluation of CCD video2camera noise [ J ] . IEEE Transactions on Circuit s and Systems for Video Technology , (2008) , 18 (2) : 280 - 284.

DOI: 10.1109/tcsvt.2007.913972

[3] Pan Wei, Zhao Yi, Ruan Xueyu. A new method for get ting high precision phase in s tructural light [ J] . Act a Optica Sinica, (2004), 24(5)687~691.

[4] Gach J L , Darson D, Guillaume C M, et al. A new digital CCD readout technique forultr a-low-noise CCDs [ J] . The Astronomical Society of the Pacific, (2003), 115( 9) : 1 068- 1 071.

DOI: 10.1086/377082

[5] FARAJ I H , MACL EAN J . CCD noise removal in digital images [J ] . I EEE T ransac.
