Structural Design and Simulation Analysis of Ejector Used in Automotive Power Steering Oil Discharge Equipment

Abstract:

The structure of ejector used in automotive power steering oil discharge equipment is designed in accordance with the theory of gas-liquid ejector.The two important parameters of the ejector are elected respectively to five values and then 25 ejector models are obtained by the permutations and combinations.The ejector’s CFD model is created by Fluent module of Ansys,then it is divided into a grid and analyzed. Analyse its pressure distribution and velocity vector, which provides the optimal size for the manufacture of the ejectors and a theoretical basis for experiment.

• Periodical: Applied Mechanics and Materials (Volume 274)
• Pages: 270-273
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.274.270
• Online since: January 2013
• Authors: Kai Cheng, Hai Lin Zou, Xiang Chao Kong, Jie Tang
• Keywords: ANSYS, Automotive Power Steering, Ejector, Fluid Analysis

References

[1] Kai Cheng , Li Yan and Guangming Li The flow analysis of the automotive power streering gear assembly's flow channel Equipment Manufacturing Technology and Automation II. (2011).

[2] Zhiyong Sheng, Numerical Simulation and Optimization Study of Small-sized Steam Ejector Ms D thesis. Donghua University. (2007).

[3] B.J. Huang, V.O. Petrenko, I.Y. Samofatov, N.A. Shchetinina, Collector selection for solar ejector cooling systems Solar Energy, vol. 71, 2001. pp.269-274.

DOI: 10.1016/s0038-092x(01)00042-1

[4] Ruijin Wang, Kai Zhang, Fluent technical foundation and examples Tsinghua University Press 2007. (In Chinese).

[5] Zhanzhong Han , Jing Wang Fluid engineering simulation calculation examples and applications Beijing Institute of Technology Press 2004. (In Chinese).
