Simulation on Multi-Oil-Cavity and Multi-Oil-Pad Hydrostatic Bearings

Abstract:

Taking multi-oil-cavity and multi-oil-pad hydrostatic bearings as studied projects, firstly make brief instructions for structure characteristics and working principal of hydraulic system; Then, build three-dimensional models of multi-oil-cavity and multi-oil-pad hydrostatic bearings respectively. Adopting finite volume method, oil film mesh is generated by universal finite analysis software CFD; then, carry on numerical simulations for pressure distribution and temperature distribution of the two studied hydrostatic thrust bearing under various viscosity, and make comparative analysis for difference between the two studied hydrostatic thrust bearing. Based on the analysis of numerical simulation results, the conclusions whether oil-return groove is set for hydrostatic bearing could be received. Simulation results reveal truly the influence of setting oil-return groove or not on hydrostatic thrust bearing, and improve structure design for hydrostatic thrust bearing.

• Periodical: Applied Mechanics and Materials (Volume 274)
• Pages: 274-277
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.274.274
• Online since: January 2013
• Authors: Xiao Qiu Xu, Jun Peng Shao, Xiao Dong Yang, Yan Qin Zhang, Xiao Dong Yu, Bing Wei Gao
• Keywords: Hydrostatic Thrust Bearing, Oil-Return Groove, Pressure Field, Temperature Field

References

[1] Zhang Y Q, Shao J P, Ni S Q: China Mechanical Engineering, Vol. 19 (2008), pp.563-565.

[2] Yu Xiaodong ; Meng Xiuli ; Bo. Wu: 2nd International Conference on Frontiers of Manufacturing and Design Science, Vol. 32(2011), pp.3477-3481.

[3] Niels Heinrichson, Ilmar Ferreira Santos, Axel Fuers: Journal of Tribology, Vol. 191(2007), pp.895-903.

[4] Xiaodong Yu, Xiuli Meng, Junpeng Shao: Electronic Measurement & Instruments, (2009), pp.1005-1010.

[5] Zhang Yanqin, Dai Chunxi, Wang Yunfei: 2011 International Conference on Electronic and Mechanical Engineering and Information Technology (2011), pp.1083-1086.

[6] Yang Peiran: Beingjing National Defence Industry Press, (1998), pp.10-26.

[7] Ding Zhenqian: Shanghai Science and Technology Press, (1986), pp.63-65.

[8] Wang Longgang: Beijing Jiaotong University, (2008), pp.31-35.
