Study on Dynamic Failure Behaviors of Steel Doble-Layer Grids (42X42m) Supported by Circumjacent Steel Columns Used in a Gymnasium under Disaster Earthquake Action

Abstract:

In this paper, the elasto-plastic dynamic analysis on dynamic failure behaviors of steel double-layer grids supported by tridimensional truss columns used in a gymnasium with the function of earthquake victims shelter under disaster earthquake is carried out under EL-centro wave with SAP2000, and the appraisal results on their anti-failure performances are presented under strong earthquake action based on the plastic-hinge theory. In the analyses, the geometric and material nonlinear effects are considered simultaneously based on the plastic-hinge theory. The plastic development level of the rod, the deformed shape and the failure type and the ductility are estimated by plastic hinge principle. The results show that the failure model of the structure under the earthquake wave action is the complicated combination of strength failure and elasto-plastic dynamic local buckling in deferent areas of the structure; When the structure reached its failure critical limit, the development of the plastic hinges is not sufficient and only 5.11% of the rods enter into their plastic stage; Its critical failure peak acceleration of EL earthquake wave when applied in the combination of three directions is 705gal and can be served as earthquake victims shelter in the area of 8 degree seismic fortification; Its displacement ductility coefficient is 2.39,which shows the structure owns good energy dissipation capacity.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 1272-1275
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.1272
• Online since: January 2013
• Authors: Yun Jing Niu, Hai Wang Li, Jing Liu
• Keywords: Elasto-Plastic Dynamic Response, Plastic Hinge, Seismic Performance, Steel Double-Layer Grids, Strong Earthquake Action

References

[1] H.W. Li, H.S. Zhao, Y.J. Zhao: Study on Planning for the Indoor-earthquake-shelter in City and Town. (Advanced Science Letters), USA, 2011, Vol. 4, p.2654–2665.

DOI: 10.1166/asl.2011.1755

[2] Civil King Software Technology Co., Ltd. China institute of Building Standard Design & Research. Usage Guide to Structure Analysis Program SAP2000 Chinese Edition [CP] (China communications press, China, 2006), p.460. (in chinese).

[3] JGJ7-2010(2010 edition) Technical specification for space frame structure [S]. (People's Republic of China on housing and urban-rural development , Beijing, 2010). (in chinese).

[4] GB50011-2010(2010 edition) Code for seismic design of buildings[S]. (China architecture & building press, Beijing, 2010). (in chinese).

[5] FEM 356 The Seismic Rehabilitation of Buildings[S]. Federal Emergency Management Agency, (2000).

[6] S.S. Zhao and C. Xin: Dynamic stability of grid structure[M] (Beijing, Science Press, 1999). (in chinese).

[7] H.W. Li, J.X. Li, F. Zhi, F. Ma and D.Q. Qin: Proceedings of the 6th International Conference on Computation of Shell and Spatial Structures IASS-IACM (Cornell University, Ithaca, NY, USA, May 28-31, 2008).

DOI: 10.1016/j.engstruct.2007.07.002
