Research and Applications of a Plane Embedded Combined Element Model Considering Bond and Slip

Abstract:

It is one of the most important issues for finite element analysis of lining structures that how to describe anchor rod reasonably and effectively and simulate the interaction between rod and concrete or rock. Virtual nodes are constructed in concrete/rock element at the ends of anchor rod and bond-slip element is set between virtual nodes and beam element which describes anchor rod. An embedded combined element with bond slip and shear deformation is established through the transformation of nodal force at nodes of bond-slip element to those of concrete/rock element via shape functions. The element is convenient for meshing element because the location and direction of anchor rod are not necessary to be considered. Meanwhile, the element has the advantage of low computing cost. Finally, the validity and efficiency are verified by numerical examples.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 1296-1301
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.1296
• Online since: January 2013
• Authors: Ji Wei Wang, Qin Qin Qiao, Fei Leng
• Keywords: Bond and Slip, Embedded Finite Element Model, Reinforced Concrete Finite Element Method, Shearing Deformation

References

[1] GuoFan Zhao, Di Zhou. Mechanical Industry Press, 2005. 129-151. (in Chinese).

[2] Changhai Wu, Jiwei Wang. Journal of Computer Aided Design And Computer Graphics, 2000. (in Chinese).

[3] Jiwei Wang, Fei Leng . Journal of Computational Mechanics, 2007. (in Chinese).

[4] JiWei Wang, XiongWen Zhang,. Engineering Mechanic, 2008. (in Chinese).

[5] JiWei Wang, XiongWen Zhang. Advances in Science and Technology of Water Resources, 2005. (in Chinese).

[6] LiDe Wei, ZhiHua Ye, CongXin Chen, XinMin Ge. Chinese Journal of Geotechnical Engineering, 2008. (in Chinese).
