Finite Element Analysis of Airflow Field for Vacuum Chamber in Air-Suction Seed Metering Device of No-Till Seeder

Abstract:

In order to study the impact of the different structures in the air-suction seed metering device of no-tillage planter on seeding performance, based on the structural characteristics of vacuum chamber in air-suction seed metering device of no-tillage planter, the air flow finite element analysis of air-suction seed metering device and experimental verification were did. Mainly the law of the distribution of airflow field and seeding performance of the vacuum chamber under the situation of the different distribution diameters of the suction hole were studied in this paper. The result shows that the adsorption performance is best when the suction hole distribution diameter is 150 mm. The conclusion can provide a reference for structural optimization and performance improvement of the air-suction seed metering device of no-tillage planter.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 547-553
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.547
• Online since: January 2013
• Authors: Yue Qin Liu, Man Quan Zhao, Yong Wen Hu
• Keywords: Adsorption Seed Performance, Airflow Field, Finite Element Analysis (FEA), Pneumatic, Seed Metering Device, Vacuum Chamber

References

[1] Guarella P, Pellerano A, Pascuzzi S: Journal of Agricultural Engineering Research Vol. 41(1996), pp.29-36.

[2] Zulin Z, Upadhyaya S K: Transactions of the ASAE Vol. 41(2)(1998), pp.307-314.

[3] Karayl D, Barat Z B, Ozmerzi A: Biosystems Engineering Vol. 87(4)(2004), pp.437-444.

[4] Molin J P: Transactions of the ASAE Vol. 37(4)(1994), pp.169-175.

[5] Far.J. Jafari, Upadhyaya S. K: Transactions of the ASAE Vol. 37(4)(1994), pp.1069-1075.

[6] Barut, Zeliha Bereket: Turkish Journal of Agricultural Machinery Vol. 28(6)(2004), pp.435-441.

[7] Nianchao Jiang, in: ANSYS and ANSYS/FE-SAFE software engineering applications and examples, edtied by Hehai University Press, China, (2006).

[8] Lidong Chen, Di He, Yufeng Xie: Journal of Agricultural Mechanization Research Vol. 28(9)(2006), pp.130-131. In Chinese.

[9] Jin Chen, Yaoming Li, Xiqiang Wang: Transactions of the Chinese Society for Agricultural Machinery Vol. 38(9)(2007), pp.59-62.

[10] Qingxi Liao, Jibo Li, Guoliang Qin: Transactions of the Chinese Society for Agricultural Machinery 40(7)(2009), pp.78-82.

[11] Pingan Du, Ezhong Gan, Yating Yu, in: Finite element method-theory, modeling and application, edtied by National Defence Industry Press, China, (2004).

DOI: 10.1109/icma.2005.1626887

[12] Chinese Agricultural Machinery Institute, in: Practical Mechanical Design Handbook (below). edtied by Mechanical Industry Press, China, (1998).

[13] Li Sun, Quan Wang, Yueting Wang: Transactions of the Chinese Society for Agricultural Machinery Vol. 19(4)(1988), pp.96-99.

[14] Lin Li: Transactions of the Chinese Society for Agricultural Machinery, Vol. 10(3)(1979), pp.56-63.
