Design of Machining Fixture for Thin-Walled and Eccentric Parts

Abstract:

The paper was conducted to solve the low machining accuracy of eccentric parts and thin-walled parts on tomato harvester, reduce the machining steps of thin-walled parts and eccentric parts, and promote the machining accuracy and labor productivity, a special fixture was designed. High concentricity machining was applied based on adjusting the fixture, and manufacturing workpiece didn’t need to dismount, thus the concentricity and machining accuracy of manufacturing workpiece can be achieved. It’s beneficial to improve productivity and production quality.

• Periodical: Applied Mechanics and Materials (Volumes 278-280)
• Pages: 261-266
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.278-280.261
• Online since: January 2013
• Authors: Rong Qing Liang, Jin Ling Cong, Jin Dong Sun, Za Kan, Cheng Song Li, Feng Jin Sun
• Keywords: Concentricity, Design, Fixture, Machining Accuracy, Thin-Walled Part
