Localization of Lamb Wave Scattering Source Based on Time-Frequency Analysis

Abstract:

Considering the influence of Lamb wave dispersion on the precision of damage detection, a new detection method of scattering source based on time-frequency curves and ellipse localization method is proposed. Empirical mode decomposition(EMD) is used to decompose the scattering signal into finite narrowband signals, and a modified continuous wavelet transform(CWT) is further used to get the time-frequency distribution(TFD) of the detected signal, and the arriving time of different frequency component is estimated based on TFD. A series of location results can be obtained from different frequency components using ellipse localization method. The damage position can finally be estimated by synthesizing localization results at different frequencies. Experiments on aluminum plate are conducted to demonstrate the efficiency of the proposed method. EMD-CWT analysis can get precise time-frequency curves in highly dispersive low frequency band of A0 mode. The damage location results is more accurate and the influence from occasional factors can be suppressed by using the synthesized method.

• Periodical: Applied Mechanics and Materials (Volume 281)
• Pages: 276-281
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.281.276
• Online since: January 2013
• Authors: Ding Ma, Li Hua Shi, Shang Chen Fu, Hong Fu Cao
• Keywords: CWT, Damage Detection, Empirical Mode Decomposition (EMD), Lamb Wave, Time-Frequency Analysis

References

[1] Zhang Haiyan, Ta Dean, Liu Zhenqing, Lamb waves in layered anisotropic composite panels [M]. Science Press. (2008).

[2] Peng Ge, Yuan Shenfang, Xu Yingdi, Damage Location of Two-Dimensional Structure Based on Wavelet Transform and Active Monitoring Technology of Lamb Wave, Journal of Vibration Engineering, 17(4): 488-493. (2004).

[3] Cai Jian, Shi Lihua, Yuan Shenfang, Improved delay-and-sum, imaging method for adjacent multi-damages[J]. Journal of Vibration and Shock, 30(8): 67-71. (2011).

[4] Xie Weihua, Tang Jun, Du Shanyi, et al, Technical Research on Active Detection and Monitoring of Damage in Metallic Plate Based on Lamb Wave, Piezoelectrics & Acoustooptics, 30(3): 349-352. (2008).

[5] Wilcox P, Lowe M, Cawley P. The effect of dispersion on long range inspection using ultrasonic guided waves. NDT&E International, 2001. 34: 1-9.

DOI: 10.1016/s0963-8695(00)00024-4

[6] Wang H C, Rose J T, Chang F G. A Synthetic time-reversal imaging method for structural health monitoring. Smart Materials and Structures, 2004, 13(2): 415-423.

DOI: 10.1088/0964-1726/13/2/020

[7] Cai Jian, Shi Lihua, Yuan Shenfang (2012), High-resolution damage imaging for composite plate structures based on virtual time reversal. Acta Materiae compositae Sinica, 29(1): 183-189.

[8] Gong Congcong, Shi Lihua, Li Gang, Enhancement of the Localization Accuracy of AE Source by Using Narrow-band Information Extraction Technology. Piezoelectrics & Acoustooptics, 31(2): 292-295. (2009).

[9] Fan Shixuan, Zhang Haiyan, Lv Donghui, Travel time extraction of multi-mode Lamb wave with HHT. Technical Acoustics, 26(4): 628-631. (2007).
