DEM Simulation of Working Speed of Spade Soil Opener Influencing on the Dynamic Behavior of the Soil

Abstract:

To research spade soil opener work performance, based on two-dimensional discrete element method, using the secondary development of CAD technology, by soil opener CAD model to construct a two-dimensional discrete element analysis model soil opener using MFC programming techniques developed two dimensional discrete element simulation system based on building a soil discrete element calculation model of the soil opener process simulation, presented on a computer spade affect the dynamic behavior of the soil, has been the destruction of soil flow deformation achieve spade Soil computer-aided design, provides a new method for the analysis into the performance of the opener, and provide a reference for the design of the cut soil components.

• Periodical: Applied Mechanics and Materials (Volume 281)
• Pages: 293-298
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.281.293
• Online since: January 2013
• Authors: Yu Jie Ji, Cheng Hua Li, Hong Da Xue
• Keywords: DEM, Simulation Analysis, Soil, Spade Soil Opener

References

[1] Chenghua Li, Bo He, Simulation and virtual reality design for spade punch planter of corn [M]. Beijing: China Agricultural University Press, (2007).

[2] Zhonghua Xu, Jianhua Wang, Advanced in Finite Element Analysis of Soil Cutting[J]. Journal of agricultural machinery, 2005, 36(1): 134-137.

[3] Cundall P A, Strack O L. A discrete numerical model for granular assembles[J]. Geotechnique, 1979. 29(1): 47-65.

[4] Guomin Liu, Meng Zou, Jianqiao Li, Interfacial dynamics simulation between soil and earthworm surface[J]. Journal of Jilin University(Engineering edition), 2010, 40(6): 1609-1613.

[5] Yi Cui, Wen Li, Jun Wang, etc, Numerical analysis on traction performance of trapezia lugged wheel by distinct element method[J]. Journal of Beijing university of aeronautics and astronautics, 2010, 36(3): 253-256.

[6] Rui Zhang, Research on the Dynamic Behacior of Soil Based on Mesocopic Simulation by Di stinct Element Method[M]. Changchun: Jilin University, (2005).

[7] Yukun Wang, Zhandi Gao, Research on Developing the Excellent Hydraulic Model Datebase of Centrifugal Pump by using MFC ODBC and ObjectARX[J]. Development & Innovation of Machinery & Electrical Products , 2005, 18(1)：85-86.

[8] Gaojie Fan, Development of Tube-in-tube Chimney CAD system Based on ObjectARX[M]. Dalian: Dalian University of Technology, (2009).

[9] Yude Dong, Han Zhao, CAD secondary development theory and technology [M]. Hefei: Hefei University of Technology Publishing House, (2009).

[10] Cundall P A. A computer model for simulating progressive large scale movement in block rock system. Symposium ISRM, 1971M Proc. 2: 129-136.

[11] Valentin L．Popov, Contact mechanics and friction physical principles and applications [M]. Trans. Qiang Li, Jianbin Luo. Beijing: Tsinghua University Press, (2011).

[12] Zhihong Li, Lanpo Zhao, Sen Dou, Pedology [M]. Beijing: Chemical Industry Press, (2005).
