Special Gripping Elements for Handling with Flat Objects

Abstract:

The paper analyses possibilities to use new materials having a high degree of adhesion for designing vacuum gripping elements with a view to increase the radial capacity and at the same time to preserve the compressed air consumption or the vacuum level. Structural modification of the suction cup is presented with a bearing supporting plate having a material with an adhesion layer on the contact boundary and allowing the down-pressure to be regulated depending on mechanical properties of the object kept. In conclusion the results achieved are summarized illustrating a marked increase of the radial load capacity with regard to the defined vacuum level and the degree of shifting in the contact profile compared with the standard suction cups with a similar geometrical diameter in relation to the contact surface.

• Periodical: Applied Mechanics and Materials (Volume 282)
• Pages: 27-32
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.282.27
• Online since: January 2013
• Authors: Marcel Horák, František Novotný
• Keywords: Adhesion, Gripping Element, Handling, Radial Loading, Vacuum

References

[1] Bartlett, M. D., Croll, A. B., King D. R., Paret, B. M., Irschick, D. J., and Crosby, A. J. Looking Beyond Fibrillar Features to Scale Gecko-Like Adhesion. Advanced Materials, Volume 24, Issue 8, Jan 2012, pp.1078-1083.

DOI: 10.1002/adma.201104191

[2] Sethi, S., Ge, L., Ci, L., Ajayan, P. M. and Dhinojwala, A. Gecko-Inspired Carbon Nanotube-Based Self-Cleaning Adhesives. Nano Letters, 2008, Vol. 8, No. 3, pp.822-825, http: /www2. uakron. edu/cpspe/dhinojwala/pdfs/SeS-2008. pdf.

DOI: 10.1021/nl0727765

[3] Ge, L., Sethi, S., Ci, L., Ajayan, P. M., and Dhinojwala, A. Carbon nanotube-based synthetic gecko tapes. PNAS, June 26, 2007, vol. 104, no. 26, p.10792–10795, http: /www2. uakron. edu/cpspe/dhinojwala/pdfs/GeL-2007. pdf.

DOI: 10.1073/pnas.0703505104

[4] Giannakopoulos, A. E., Venkatesh, T. A., Lindley, T. C. and Suresh, S. The Role of Adhesion in Contact Fatigue. Acta mater. Vol. 47, No. 18, 1999, pp.4653-4664, http: /nanomechanics. mit. edu/papers/Role_Adhesion_99. pdf.

DOI: 10.1016/s1359-6454(99)00312-2

[5] Horák, M., Novotný, F. Deformation Analysis of Suction Cup under Combined Load. In proceedings: 10th International Carpathian Control Conference. Zakopane: University of Science and Technology. Poland, 2009, pp.403-406, ISBN 83-89772-51-5.

[6] Novotný, F., Horák, M. Problems of Loading Capacity of Suction Cups in the Radial Direction. In: Proceedings of the Fifth International Conference on Optimisation of the Robots and Manipulators, Calimanesti, Romania, 2010, pp.70-74.

DOI: 10.4028/www.scientific.net/amr.463-464.1291

[7] Horák, M., Novotný, F. Increases in the Radial Capacity of Vacuum Gripping Elements. MM Science Journal, October 2011, Special Edition - 20th International Workshop on Robotics in Alpe-Adria-Danube Region (RAAD), October 5-7 2011, MKČR E 7645, www. mmscience. eu, pp.122-127.

DOI: 10.1109/raad.2010.5524538

[8] Horák, M., Novotný, F. Podtlakový úchopný prvek. Užitný vzor, číslo zápisu 22075, 18. 4. 2011, MPT B 65 G 47/91, Úřad průmyslového vlastnictví ČR (www. upv. cz).

[9] Horák, M., Novotný, F. Podtlakový úchopný prvek. Patent, číslo 302959, 14. 12. 2011, MPT B 65 G 47/91, B 65 H 5/14, B 60 R 9/058, Úřad průmyslového vlastnictví ČR (www. upv. cz).
