Reinforced Concrete Finite Element Analysis Incorporating Material Nonlinearity and Failure Criteria Aspects

Abstract:

The behavior of concrete is highly nonlinear, even at very low loading levels. Steel, on the other hand, exhibits a relatively linear behavior up till yielding. The synergy between the two materials and their compatibility has long been the subject of research. While the failure criterion for steel is straight forward, concrete can be approached by various theories. The most prominent are the Kupfer-Hilsdorf-Rusch and the Möhr failure envelope. The behavior of material under bi-axial stresses subsequent to cracking can be assumed isotropic or orthotropic, resulting in a differentiation in the material constitutive matrix formulation. This work covers the finite element modeling of reinforced concrete elements, based on the two failure envelopes, while assessing the isotropic and orthotropic methodology. The Finite Element smeared crack approach is used to analyze stresses and the propagation of cracking pattern for the element. The resulting load – displacement curves are validated with identical laboratory tested specimens.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 1230-1234
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.1230
• Online since: January 2013
• Authors: Tud Jono Sri, Aylie Han, Lie Hendri Hariwijaya
• Keywords: Failure-Criteria, Material Behavior, Nonlinearity

References

[1] H. Kupfer, H.K. Hilsdorf, and H. Rusch: Behavior of Concrete under Biaxial Stresses, ACI Journal, Proceedings, Vol. 66, No. 8, (1969), p.656.

[2] H. Fossen: Structural Geology, Cambridge University Press, (2010)

[3] N.S. Ottosen: Constitutive Model for Short-Time Loading of Concrete, Journal of the Engineering Mechanics Division, ASCE, Vol. 105, No. EM1, (1979), p.127.

DOI: 10.1061/jmcea3.0002446

[4] K.K.B. Dahl: Uniaxial Stress-Strain Curves for Normal and High Strength Concretes, Rapport 7.6, Project 7, Department of Structural Engineering, Technical University of Denmark, (1992).

[5] A. Hillerborg, M. Modéer and P.E. Petersson: Analysis of crack formation and crack growth in concrete by means of fracture mechanics and finite elements, Cement and Concrete Research, Vol. 6, No. 6, (1976), p.773.

DOI: 10.1016/0008-8846(76)90007-7

[6] F.J. Vecchio and M.P. Collins: The Modified Compression-Field Theory for Reinforced Concrete Elements Subjected to Shear, ACI Journal Proceedings, Vol. 83, No. 2, (1986), p.219.

DOI: 10.14359/10416

[7] H.G. Kwak and F.C. Filippou: Finite Element Analysis of Reinforced Concrete Structures Under Monotonic and Cyclic Loads,10th World Conference in Earthquake Engineering, Madrid, Spain, (1992).

[8] I.Y. Jang, H.G. Park, S.S. Kim, J.H. Kim and Y.G. Kim: On the Ductility of High-Strength Concrete Beams. International Journal of Concrete Structure and Material, Vol. 2 No. 2. (2008), p.115.
