The Application of MRI for Scanning Internal Cracks of Cement-Based Material

Abstract:

Regarding the internal structure of cement-based materials, some major concerns the mode of distribution of pores, pore size, and the type in which they are connected. A thorough understanding of the distributive rules of pores and the approaches to break their links will be a considerable contribution to enhancing the durability of cement-based materials. There are several methods to discover the pores of cement-based materials, but cannot show the exact location of pores and the structural links. Magnetic resonance imaging (MRI) has been widely applied to physical examinations. This technique has matured and is now able to obtain information and 3-D images about the organs of recipients without causing damage. The signals from MRI indicate where the hydrogen nucleus is located. However, MRI is seldom used for cement-based materials. In this study, we use H2O as the source of MR image signals in the mortar. Through this experiment, we verify that MRI can be used to analyze the distribution of internal cracks in cement-based material.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 1242-1246
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.1242
• Online since: January 2013
• Authors: Hsiang Wei Chiang, Ran Huang, Chia-Jung Tsai
• Keywords: Cement-Based Material, Crack, Magnetic Resonance Imaging (MRI)

References

[1] Bushong, S. C., Magnetic resonance imaging: Physical and biological principles, 2nd ed. St. Louis: Mosby-Year Book, (1996).

[2] Information on http: /www. cis. rit. edu/htbooks/mri.

[3] Chou, M. C., Tsai, P. H., Huang, G. S., Lee, H. S., Lee, C. H., Lin, M. H., Lin, Chien-Yuan ., and Chung ,H. W, Correlation between the MR T2 value at 4. 7 T and relative water content in articular cartilage in experimental osteoarthritis induced by ACL transaction, Osteoarthritis and Cartilage, Vol. 17(4) (2009).

DOI: 10.1016/j.joca.2008.09.009

[4] Huang , GS., Lee , HS., Chou , MC ., Shih , YY., Tsai , PH., Lin , MH ., Lin , Chien-Yuan ., Lee , CH ., Chung , HW, Quantitative MR T2 measurement of articular cartilage to assess the treatment effect of intra-articular hyaluronic acid injection on experimental osteoarthritis induced by ACLX, Osteoarthritis and CartilageVol. 18(2010).

DOI: 10.1016/j.joca.2009.08.014

[5] Lin, Chien-Yuan., Lin, Ming-Huang., Cheung, Wai-Mui., Lin, Teng-Nan., Chen, Jyh-Horng., and Chang Chen, In Vivo Neuro-microvasculatural Visualization using 3D ΔR2-Based Microscopy of Magnetic Resonance Angiography (3DΔR2-mMRA), NeuroImage Vol. 45(3) (2009).

DOI: 10.1016/j.neuroimage.2008.12.030

[6] J. F. Young, and S. Mindness, The Science and Technology of Civil Engineering Materials, Prentice Hall, (1998).

[7] J.J. Young , P. Szomolanyi, T.W. Bremner, B.J. Balcom, Magnetic resonance imaging of crack formation in hydrated cement paste materials, Cement and Concrete Research Vol. 34(2004) 1459–1466.

DOI: 10.1016/j.cemconres.2004.01.023

[8] S.J. Jaffer, C. Lemaire, C.M. Hansson, and H. Peemoeller, MRI: A complementary tool for imaging cement pastes, Cement and Concrete Research, Vol. 37 (2007), 369–377.

DOI: 10.1016/j.cemconres.2006.07.003

[9] Md. Safiuddin, Nataliya Hearn, Comparison of ASTM saturation techniques for measuring the permeable porosity of concrete, Cement and Concrete Research, Vol. 35 (2005), 1008-1013.

DOI: 10.1016/j.cemconres.2004.09.017
