A Low Power CMOS Bulk-Controlled Sub-Harmonic Mixer for LTE-Advanced Applications

Abstract:

In this paper, a 3.5 GHz CMOS sub-harmonic mixer for LTE-advanced applications is presented. The mixer with the bulk-controlled technique improves the linearity and mitigates the power of the local oscillator. The proposed mixer is implemented by tsmc 0.18 μm Mixed Signal RF CMOS 1P6M process and consumes 2.2 mA from a 1.2 V supply. The proposed mixer operates at 3.5GHz LTE-advanced bands and achieves maximum input third-order intercept point (IIP3) of 2.3dBm, power conversion gains of 1.3 dB.

You might also be interested in these eBooks

Innovation for Applied Science and Technology

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 284-287)

Pages:

2423-2427

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.284-287.2423

Citation:

Cite this paper

Online since:

January 2013

Authors:

Hung Che Wei, Chih Lung Hsiao

Keywords:

Linearity, Long Term Evolution (LTE), Mixer, Sub-Harmonic

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] B. Razavi: RF Microelectronics (Prentice-Hall, New Jersey 2011).

Google Scholar

[2] L. Sheng, J.C. Jensen and L.E. Larson: A wide-bandwidth Si/SiGe HBT direct conversion subharmonic mixer/downconverter. IEEE J. Solid-State Circuits. Vol. 35 No. 9 (2000), pp.1329-1337.

DOI: 10.1109/4.868044

Google Scholar

[3] T. Yamaji, H. Tanimoto and H. Kokatsu: A I/Q active balanced harmonic mixer with IM2 cancellers and a 45± Phase shifter. IEEE J. Solid-State Circuits. Vol. 33 No. 12 (1998), pp.2240-2246.

DOI: 10.1109/4.735708

Google Scholar

[4] M. Goldfarb, E. Balboni and J. Cavey: Even harmonic double-balanced active mixer for use in direct conversion receivers. IEEE J. Solid-State Circuits. Vol. 38 No. 10 (2003), pp.1762-1766.

DOI: 10.1109/jssc.2003.817602

Google Scholar

[5] B. Razavi: Design of Analog CMOS Integrated Circuits (Mc Graw Hill, New York 2001).

Google Scholar

[6] M. Gilasgar: A 2.4GHz 1.8-V CMOS Sub-harmonic Mixer with Inherent Harmonic-Rejection, Presented at Proc. Int. Conf. Intelligent Systems, Modelling and Simulation, Liverpool, United Kingdom, (2010).

DOI: 10.1109/isms.2010.79

Google Scholar

[7] M.F. Huang, S.Y. Lee and C.J. Kuo: A 5.25 GHz Even Harmonic Mixer for Low Voltage Direct Conversion Receivers, Presented at Proc. Asian Solid-State Circuits Conf., Hsinchu, Taiwan, (2005).

DOI: 10.1109/asscc.2005.251730

Google Scholar
