A Single-Phase Soft-Switching Unipolar PWM Rectifier

Abstract:

This paper proposed a novel single-phase soft-switching unipolar PWM rectifier (SSUPR) using a simple auxiliary resonant unit. All main switches of high-frequency arm operate at zero-voltage-switching (ZVS) turn-on, while the auxiliary switches operate at zero-current-switching (ZCS) turn-off. All main switches of low-frequency arm operate at 60 Hz to greatly reduce switching losses. Moreover, a soft-switching unipolar PWM strategy is used for the proposed soft-switching rectifier. This strategy results in a better input current waveform than for the bipolar PWM strategy. Furthermore, the proposed rectifier achieves a near unity power factor, a sinusoidal input current and a bidirectional power flow capability. Some experimental results of the proposed SSUPR, rated 500 W and operated at 40 kHz, are presented for verification.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 2439-2444
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.2439
• Online since: January 2013
• Authors: Maoh Chin Jiang, Huang Kai Fu, Kao Yi Lu
• Keywords: Unipolar PWM Rectifier, Zero Voltage Switching (ZVS), Zero-Current-Switching (ZCS)

References

[1] N. Mohan, T.M. Undeland, and W.P. Robbins, in: Power electronics: converters, applications and design, John Wiley and Sons (2003).

[2] C.M. Wang, C.H. Su, C.H. Lin, M.Y. Liu, M.C. Jiang, and K.L. Fang: A ZVS-PWM Voltage-Doubler Rectifier with High Power Factor, Proceeding of the IEEE International Conference on Industrial Technology, (2008), pp.1-5.

DOI: 10.1109/icit.2008.4608559

[3] X. Yuan and I. Brabi: Analysis, Designing, and Experimentation of a Transformer-Assister PWM Zero-Voltage-Switching Pole Inverter, IEEE Trans. on Power Electronics, (2000), Vol. 15, pp.72-82.

DOI: 10.1109/63.817365

[4] G. Hua and C.S. Leu and F.C. Lee: Novel Zero-Voltage-Transition PWM Converters, IEEE Trans. on Industrial Electronics, (1995), Vol. 42, pp.595-603.

DOI: 10.1109/pesc.1992.254691

[5] A.F. de Souza and I. Barbi: A new ZVS-PWM Unity Power Factor Rectifier with Reduced Conduction Losses, IEEE Transaction on Power Electronics, (1995), Vol. 10, pp.746-752.

DOI: 10.1109/63.471294

[6] O. Garcia, J. Cobos, R. Prieto, P. Alou, and J. Uceda:  Single Phase Power Factor Correction: A Surrey, IEEE Trans. Power Electron., (2003), Vol. 18, pp.749-755.

DOI: 10.1109/tpel.2003.810856

[7] O. Stihi and B.T. Ooi: A Single-Phase Controlled-Current PWM Rectifier, IEEE Trans. on Power Electronics, (1988), Vol. 3, pp.453-459.

DOI: 10.1109/63.17967

[8] W. MeMurray: Resonant Snubber With Auxiliary Switches, Proceeding of the IEEE Industry Applications Society Annual Meeting, (1993), pp.355-362.

[9] M.C. Jiang, G.B. Tu, C.H. Chen and C.T. Chen: Analysis and Design of a Novel Soft-Switching Three-Phase Inverter, Proceeding of the International Conference on Power Electronics, (2010), pp.125-130.

DOI: 10.1109/ipec.2010.5543861
