Measurement of Radius of Curvature by Coordinate Measurement Machine

Abstract:

Radius of curvature is one of the key parameters of optical components. A variety of methods have been developed for this measurement. This paper describes a novel way, named “CMM spherometry by probe compensation”, to measure the radius of curvature of optical surfaces by coordinate measuring machine (CMM). The measurement combines CMM measurement and iteration calculation scheme is presented. The measurement results of CMM and the trace samples are compared. The effect of temperature compensation is discussed.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 488-492
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.488
• Online since: January 2013
• Authors: Shenq Tsong Chang, Wei Cheng Lin, Ting Ming Huang, Ming Ying Hsu, Po Hsuan Huang
• Keywords: CMM, Probe Compensation, Radius of Curvature, Temperature Compensation
