A Finite Element Approach to Dynamic Stresses of Helical Gear Pairs Considering Tip Relief and Crowning Modifications

Abstract:

A dynamic finite element (FE) approach to contact and fillet bending stresses of helical gear pairs (HGPs) is presented. Using derived tooth profiles, high quality elements of HGPs can be efficiently constructed. The resulted maximum stresses of elements on teeth are 3D illustrated. Design of relief and profile modifications is also condisered. The effect of tooth modifications on HGP dynamic responses including misalignment errors is discussed. It shows adequate modification of tip relief and crowning can reduce dynamic stress peaks of HGPs.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 577-581
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.577
• Online since: January 2013
• Authors: Kuo Jao Huang, Ching Ya Su
• Keywords: Crowning, Dynamic, Finite Element, Helical Gear, Misalignment, Tip Relief
