A Sensing Device on Liquid Density

Abstract:

This study presents a device, which can be used to detect density of various liquid. The device is composed of at least three buoys and a mechanism that is balanced by rotary moment. The design of the device presented in this study is based on the moment balanced position of the buoy on liquid. Designing parameters such as mass and volume of the buoys, relative angles of installation, and distance between the mass center and rotation center are adjustable. The device can be designed not only as a detector of liquid density but also a logic sensor of liquid density. The device will turn over and rotate 180^o when density of the liquid reached some value, which can be preset in designing by adjusting relative parameters. The device has been practically tested that when the density of liquid changes from 1 g/cm³ to 0.933 g/cm³, the position of balanced angle changes about 90^o. Turn over rotation occurs at the density of 0.933 g/cm³, which is about 2.8% of error from the designed value, 0.96 g/cm³. This device is proved to be feasible.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 582-586
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.582
• Online since: January 2013
• Authors: Ya Chien Chung, Tzyy Yih Yang, Chen Tung Chi, Jin Yih Lin, Wei Chun Cheng, Jhih Yang Jhang
• Keywords: Liquid Density, Rotary Moment Balancing, Sensing

References

[1] M. Baldauf and W. Preidel, Status of the development of a direct methanol fuel cell, Journal of Power Sources, 84 (1999), pp.161-166.

DOI: 10.1016/s0378-7753(99)00332-8

[2] Chia-Hung Weng, A strategy of estimating fuel concentration in a direct liquid-feed fuel cell system, Master thesis of Technology and Science Institute of Northern Taiwan, (2006).

[3] Shen-Hwa Chen, An instrument-based testing platform for direct methanol fuel cell and implementation of algorithm verification for fuel control, Master thesis of Technology and Science Institute of Northern Taiwan, (2009).

[4] Yu-Jen Chiu and Hsin-Chung Lien, A strategy of estimating fuel concentration in a direct liquid-feed fuel cell system, Journal of Power Sources, 159 (2006), pp.1162-1168.

DOI: 10.1016/j.jpowsour.2005.12.099

[5] C. Y. Chen, D. H. Liu, C. L. Huang and C. L. Chang, Portable DMFC system with methanol sensor-less control, Journal of Power Sources, 167 (2007), pp.442-449.

DOI: 10.1016/j.jpowsour.2007.02.056

[6] Ya-Chien Chung, Yi-Shen Chen, Feng-Yi Deng and Yu-Lin Tang, Concentration Detector, Patent No. M291094, Taiwan R.O.C. (2006).
